Specifications - 295 Loader
Model number: 295
Mounting height: 29" (nominal)
Typical range: 27" to 31"
Description Bucket Lift
Bore 2.00 2.50
Rod 1.25 1.50
Stroke 20.63 20.63
Extended Lenth 52.63 53.63
Retracted Length 32.00 33.00
A - Maximum lift height (full height): 114"
B - Clearance with bucket dumped (full height): 97"
C - Reach (full height): 22"
D - Maximum dump angle (full height): 25°
F - Bucket rollback angle (ground): 32°
G - Digging depth: 2.2"
H - Overall height in carry position: 60.9" (5.2')
R - Rollback angle at full height: 117°
Estimated breakout force: 1850 lbs
Estimated lift capacity: 1460 lbs
Notes:
1 - Estimated values assume 2500 psi lift cylinder pressure
2 - Breakout force estimated as per ASAE S301.2 - 4.1.2 (net payloud applied at cutting edge)
3 - Lift capacity estimated a per ASAE S301.2 - 4.1.1 (net payload applied at bucket midpoint)
