Allied 495 - Sub Frame Parts List

27
Parts - 495 & S495 Loader
Item Part # Description Qty
495
Qty
S495
1 31607 495 Sub Frame Weldment Left 1
2 31606 495 Sub Frame Weldment Right 1
1 31611 495 S Sub Frame Weldment Left 1
2 31610 495 S Sub Frame Weldment Right 1
3 113253 Hook Weldment 2 2
4 112747 Plate Clamp 2 2
5 112746 Spacer Block 4 4
6 112748 Shim 2 2
7 112663 Cross Member Weldment 1 1
8 112668 Tube Cross Member 1 1
9 112642 Shaft Pivot 1.75 Dia x 5.50 Lg 2 2
10 113281 Bolt Retainer Weldment 2 2
11 113746 Loader Lift Lock Weldment 2 2
12 812717 Grommet 0.375 ID x 1.00 gr5 Pl 2 2
13 812026 Bolt Hex 0.313nc x 1.00 gr5 Pl 2 2
14 812882 Bolt Car. 0.625nc x 2.50 gr5 Pl 4 4
15 812944 Bolt Car. 0.625nc x 3.00 gr5 Pl 8 8
16 84127 Bolt Car. 0.625nc x 3.50 gr5 Pl 2 2
17 812939 Bolt Hex 0.875nc x 10.00 gr8 Pl 2 2
18 81967 Nut Lock (Nylon) 0.625nc gr8 Pl 14 14
19 81723 Washer Lock 0.875 Pl 2 2
20 112730 Washer Boot 2 2
21 112812 *Decal - General Caution 2 2
22 113385 *Decal - 495 x 1.40 2 2
23 112615 *Decal - S x 1.40 2
24 112982 *Decal - Lift Lock Instructions 2 2
25 112983 *Decal - Warning Overhead Hazard 2 2
26 113474 *Decal - Cross Member Caution 2 2
*Part of decal replacement kit X1245
