Allied 495 - Main Frame Parts List

29
Parts - 495 & S495 Loader
Item Part # Description Qty 495 Qty 495S
1 31605 495 Main Frame Weldment 1 -
31609 S495 Main Frame Weldment - 1
2 24296 Quick Attach Weldment Left 1 1
3 24297 Quick Attach Weldment Right 1 1
4 112798 Tube Cross Qtach 1 1
5 108827 Pin Weldment 2 2
6 113433 Stand Weldment 2 2
7 113114 Strap Stand 2 2
8 24329 Wrench Mounting 1 1
9 110907 Pin 0.625 Dia Stand 2 2
10 12779 Hair Pin Clip #9 Western Wire 5 5
11 11325 Leveling Rod (54.0") 1 1
12 112954 Pin 1.25 Dia. x 6.75 Long 4 4
13 112955 Pin 1.25 Dia. x 5.00 Long 4 4
14 112800 Pin Qtach 4 4
15 113766 Bushing 1.25 ID x 1.50 OD x 1.375 Long 8 8
16 24242 Tube Cover 1 1
17 24458 2.5 Dia. x 20.63 Bucket Cylinder 2 2
18 24476 2.5 Dia. x 20.50 Lift Cylinder 2 2
19 81581 Bolt Hex 0.375nc x 2.50 Gr5 Pl 16 16
20 81669 Bolt Hex 0.625nc x 3.50 Gr5 Pl 4 4
21 81592 Nut Hex 0.375nc x 3.50 Gr5 Pl 4 4
22 81344 Nut Lock (nylon) 0.375nc GrB Pl 20 20
23 81967 Nut Lock (nylon) 0.625nc GrB Pl 6 6
24 81570 Washer Flat Std 0.375 Hs Pl 4 4
25 112614 *Decal - Allied x 1.75 2 2
26 52281-000 *Bright Orange Scotchal #72368 10 ft 10 ft
27 113488 *Decal - Quick Attach Instruction 2 2
*Part of decal replacement kit X1245
