508033-02 Issue 2135 Page 25 of 48
HEATING COMPONENTS
Air Gas Plenum
Burner
Gasket
Orifice Housing
Gas Valve
Air Orifice
Sensor
Ignitor
Gas Orifice
Thermal
Switch
(location)
Intake Air Screen
Intake Air
Elbow
Figure 13.
