Allied A96UH1E - Final Blower Performance Data; A96 UH1 E135 D20 Performance (Less Filter); Table 19. Allowable Heating Speeds; Table 20. Allowable Circulation Speeds

508297-01 Page 53 of 57Issue 2219
A96UH1E135D20 Performance (Less Filter)
External
Static
Pressure
in. w.c.
Air Volume / Watts at Various Blower Speeds
Bottom Return Air, Side Return Air with Optional Return Air Base, Return Air from
Both Sides or Return Air from Bottom and One Side.
Single Side Return Air - Air volumes in bold require eld fabricated transition to
accommodate 20 x 25 x 1 in. air lter in order to maintain proper air velocity.
High Medium - High Medium Medium - Low Low High Medium - High Medium Medium - Low Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00
2400 920 2205 709 2035 513 1800 363 1625 268 2280 929 2100 703 1935 531 1720 368 1550 269
0.10
2370 930 2170 718 1985 524 1760 375 1585 279 2245 941 2075 720 1910 543 1700 380 1530 280
0.20
2345 937 2150 723 1960 552 1725 385 1535 291 2210 957 2050 745 1895 558 1695 396 1500 295
0.30
2305 958 2120 744 1920 565 1690 404 1505 305 2200 978 2030 757 1850 569 1675 408 1475 308
0.40
2275 974 2070 763 1885 576 1665 419 1475 323 2175 990 2015 774 1845 584 1640 427 1450 326
0.50
2230 986 2055 779 1845 593 1620 433 1435 330 2145 989 2010 783 1820 603 1605 446 1410 332
0.60
2195 988 2030 796 1810 614 1590 451 1385 348 2125 980 1990 809 1785 618 1580 455 1375 351
0.70
2125 961 1985 806 1780 626 1545 468 1355 359 2060 937 1960 819 1765 635 1545 474 1340 366
0.80
2065 931 1965 822 1760 642 1500 479 1310 377 1980 912 1925 825 1730 646 1510 491 1295 379
Models Red Yellow Blue Brown Black
030 Allowed Factory Setting Allowed Allowed Not Allowed
045 Allowed Factory Setting Allowed Allowed Not Allowed
070 Not Allowed Not Allowed Factory Setting Allowed Not Allowed
090 Allowed Factory Setting Allowed Allowed Not Allowed
110 Not Allowed Allowed Factory Setting Allowed Not Allowed
135 Not Allowed Allowed Factory Setting Not Allowed Not Allowed
Table 19. Allowable Heating Speeds
Model Red Yellow Blue Brown Black
All Models Factory Setting Not Allowed Not Allowed Not Allowed Not Allowed
Table 20. Allowable Circulation Speeds
