1739461
Revision C
en
Operator’s Manual
es
Manual del operador
Hydro Tractors
Mfg. No. Description
2690874 LT23420, 23 Gross HP* & 42” Mower Deck
2690875 LT24460, 24 Gross HP* & 46” Mower Deck
2690995 LT23420, 23 Gross HP* & 42” Mower Deck
2690995-01 LT23420, 23 Gross HP* & 42” Mower Deck
2690996 LT24460, 24 Gross HP* & 46” Mower Deck
2690996-01 LT24460, 24 Gross HP* & 46” Mower Deck
2691089-00 LT20420, 20 Gross HP* & 42” Mower Deck
*See Speci cations for power rating information.
Mower Decks
Mfg. No. Description
1695602 42” Mower Deck
1695603 46” Mower Deck
AC130 Series
fr
Manuel d’utilisation
Not for
Reproduction

Questions and Answers

  • C
    Crystal BlairAug 12, 2025
    Why won't my Allis-Chalmers Lawn Mower engine turn over?
    • M
      Mark CunninghamAug 12, 2025
      If your Allis-Chalmers Lawn Mower engine won't turn over or start, make sure the brake pedal is fully depressed, the PTO (electric clutch) switch is in the OFF position, and the cruise control is in the NEUTRAL/OFF position. Also, check if you are out of fuel. If the engine is hot, allow it to cool before refilling the fuel tank. If the engine is flooded, disengage the choke. Other potential causes include a blown fuse (see authorized dealer), discharged or dead battery (recharge or replace), loose or broken wiring (visually check, see authorized dealer if frayed or broken), or faulty solenoid, starter motor, safety interlock switch, water in fuel, or old/stale gas (see authorized dealer).
  • A
    Ashley McdonaldAug 16, 2025
    What to do if Allis-Chalmers ac130 Lawn Mower engine stalls when mower is engaged?
    • M
      Marc RussellAug 16, 2025
      If your Allis-Chalmers Lawn Mower engine stalls easily with the mower engaged, ensure the engine speed is set to full throttle and that you're not moving too fast. Also, when cutting tall grass, set to maximum cutting height during the first pass. Additionally, ensure the engine is warmed up by running it for several minutes and start the mower in a cleared area.
  • L
    Lindsay WrightAug 19, 2025
    Why Allis-Chalmers Lawn Mower engine runs but tractor won't drive?
    • M
      Michelle WrightAug 20, 2025
      If your Allis-Chalmers Lawn Mower engine runs, but the tractor won't drive, make sure the ground speed control pedals are depressed and the transmission release lever is in the DRIVE position. Also, check that the parking brake is disengaged.
  • W
    William HendricksAug 25, 2025
    How to fix Allis-Chalmers Lawn Mower that starts hard?
    • E
      Erin HendersonAug 25, 2025
      If your Allis-Chalmers Lawn Mower engine starts hard or runs poorly, the fuel mixture may be too rich, so you should clean the air filter.
  • K
    Karen HernandezAug 27, 2025
    Why is the exhaust from my Allis-Chalmers ac130 Lawn Mower black?
    • R
      Rick BarnettAug 27, 2025
      If the exhaust from your Allis-Chalmers Lawn Mower engine is black, the air filter may be dirty, or the choke may be closed. Open the choke.
  • M
    Michael WilliamsAug 31, 2025
    How to improve cut quality on Allis-Chalmers Lawn Mower?
    • C
      Christina Duncan DVMAug 31, 2025
      If your Allis-Chalmers Lawn Mower cut is rough looking, set to full throttle and slow down the ground speed.
  • Z
    Zachary ConleySep 3, 2025
    Why is my Allis-Chalmers ac130 engine knocking?
    • A
      Anna MckenzieSep 3, 2025
      If your Allis-Chalmers Lawn Mower engine is knocking, check the oil level and add oil if required. Make sure you are using the correct grade of oil.
  • T
    thomastonySep 7, 2025
    What to do if mower won't drive on Allis-Chalmers ac130?
    • R
      Rachel LeeSep 8, 2025
      If your Allis-Chalmers Lawn Mower engine runs and the tractor drives, but the mower won't drive, engage the PTO.

Summary

OPERATOR SAFETY

General Operating Safety

Essential principles for safe operation and operator responsibility.

Children and Reverse Operation Safety

Critical warnings regarding children and safe operation in reverse.

Slope Operation Hazards

Risks and precautions for operating the tractor on inclines.

Equipment Hazards

Warnings about moving parts, thrown objects, and fuel handling.

FEATURES AND CONTROLS

Key Control Functions

Details on PTO, ignition, pedals, seat, fuel, brake, cruise, and height adjustments.

OPERATION

Safety Interlock System Tests

Procedures to verify the tractor's safety interlock system functionality.

Starting and Refueling Procedures

Safe instructions for adding fuel and starting the engine.

Driving and Mowing Operations

Guidance on driving, mowing, and reverse mowing operations.

TROUBLESHOOTING

Allis-Chalmers ac130 series Specifications
