www.allischalmerslawn.com
NOTE: Specifications are correct at time of printing and are subject to change without notice.
* Actual sustained engine power will likely be lower due to operating limitations and environmental factors. Please refer to ‘Engine Power Rating Information’ for further
details.
Manual No. 7103187 (Rev. ‘-’, 2/19/2009)
ALL-WHEEL-STEER
LAWN TRACTOR
SERIES 0
Models
AC23460AWS (49-State) (7800511)
AC23460AWS (California) (7800543)
Operator's Manual
Not for
Reproduction

Questions and Answers

  • M
    Michael MarksSep 3, 2025
    What to do if Allis-Chalmers Lawn Mower grass does not discharge correctly?
    • R
      Rachel WrightSep 4, 2025
      If the grass isn't discharging correctly from your Allis-Chalmers Lawn Mower: 1. Stop the engine and clean the mower deck. 2. Raise the height of cut. 3. Sharpen or replace the blade(s). 4. Use a slower ground speed. 5. Move the throttle control to the FAST position. 6. Replace the spring for the blade idler.
  • E
    Elizabeth RileySep 18, 2025
    What to do if Allis-Chalmers Lawn Mower rear wheels spin over uneven terrain?
    • M
      Melissa CuevasSep 18, 2025
      If the rear wheels of your Allis-Chalmers Lawn Mower spin on uneven terrain, check the front axle. If it doesn't pivot freely, loosen the axle bolt(s).
  • K
    Keith WrightSep 16, 2025
    What to do about belt noise when the brake pedal is released on Allis-Chalmers Lawn Mower?
    • A
      Alison MaySep 16, 2025
      Temporary belt noise after releasing the brake pedal on your Allis-Chalmers Lawn Mower doesn't affect operation. If the noise is continuous, check the belt routing to ensure it's inside all belt guides.
  • J
    Jesus WestSep 14, 2025
    Why Allis-Chalmers Lawn Mower moves slower or stops when the speed control pedal is depressed?
    • J
      John WilsonSep 14, 2025
      If your Allis-Chalmers Lawn Mower moves slower or stops when you press the speed control pedal: * Check the motion drive belt to make sure it's correctly installed. * Replace the motion drive belt.
  • T
    Tracy RamirezSep 12, 2025
    What to do if Allis-Chalmers Lawn Mower will not move when the brake is released and the speed control pedal is depressed?
    • B
      Brandon ChambersSep 13, 2025
      If your Allis-Chalmers Lawn Mower won't move when you release the brake and press the speed control pedal: * Release the automatic drive disconnect. * Check the motion drive belt to ensure it is installed correctly. * Replace the motion drive belt.
  • T
    Tonya AndersonSep 12, 2025
    Why Allis-Chalmers Lawn Mower blades will not rotate?
    • S
      Stacy SchultzSep 12, 2025
      If the blades on your Allis-Chalmers Lawn Mower aren't rotating: * Check the mower drive belt(s) to ensure they are installed correctly. * Replace the mower drive belt(s).
  • S
    Stephanie WardSep 9, 2025
    What causes a decrease in power in a hot Allis-Chalmers Lawn Mower engine?
    • O
      orrtheresaSep 9, 2025
      If a hot engine is causing a decrease in power in your Allis-Chalmers Lawn Mower: * Clean the air screen. * Check the oil level. * Replace the fuel filter.
  • M
    Maria CopelandSep 7, 2025
    Why Allis-Chalmers Lawn Mower housing does not cut level?
    • J
      Jesse GilesSep 7, 2025
      If the mower housing on your Allis-Chalmers Lawn Mower isn't cutting level: 1. Check the air pressure in the tires. 2. Adjust the level of the mower deck. 3. Inspect the front axle; if it doesn't pivot freely, loosen the axle bolt(s).
  • B
    Brittany PerkinsSep 5, 2025
    Why Allis-Chalmers Lawn Mower engine stops on slopes?
    • N
      npattersonSep 5, 2025
      If your Allis-Chalmers Lawn Mower engine stops when you're on slopes: * Mow up and down the slopes, never across. * Ensure you are sitting in the middle of the seat to activate the seat sensor.
  • K
    kristina53Aug 20, 2025
    Why Allis-Chalmers Lawn Mower engine will not start?
    • S
      Stephen JohnsonAug 21, 2025
      If your Allis-Chalmers Lawn Mower engine won't start, here are a few things to try: 1. Follow the steps outlined in the “How To Start The Engine” section of this book. 2. If you have an electric-start model, clean the battery terminals and tighten the cables. 3. Drain the fuel tank, clean the fuel line, and replace the fuel filter. 4. Remove the spark plug(s), move the throttle to the SLOW position, turn the ignition key to the ON position, and try starting the engine several times. Then, reinstall the spark plug. 5. Replace the spark plug.

Summary

Safety

Important Operator Safety Instructions

Essential safety guidelines for operating the lawn tractor.

Protection for Children

Precautions to prevent child injury or accidents during operation.

Protection against Tipovers

Warnings and procedures to prevent tip-over accidents on slopes.

Safe Handling of Gasoline

Guidelines for safe storage, transfer, and use of gasoline.

Operation

How to Engage the Blades

Procedure for engaging and disengaging the mower blades.

How to Use the Speed Control Pedal

Instructions for operating the hydrostatic drive system's speed pedal.

Driving and Stopping the Unit

Procedures for driving, steering, and stopping the tractor safely.

How to Stop the Unit

Procedures for safely stopping the tractor and its components.

Mowing

Guidance on optimal mowing techniques and deck operation.

Reverse Mowing Option (RMO)

Instructions and safety warnings for mowing in reverse.

How to Operate the Unit on Hills

Safety advice and operating procedures for mowing on slopes.

All-Wheel Steering

Explanation of the all-wheel steering system and its maneuverability.

Engine Operation

Procedures for starting and operating the tractor's engine.

Maintenance

Maintenance Schedule

A schedule outlining required maintenance tasks based on frequency.

How to Check and Adjust the PTO Clutch

Procedures for adjusting the PTO clutch for proper engagement and stopping time.

How to Check and Adjust the Motion Drive Belt

Instructions for inspecting and adjusting the motion drive belt tension.

How to Check and Adjust the Drive Brake

Steps for adjusting the drive brake to ensure proper stopping.

Troubleshooting

Troubleshooting Chart

A guide to diagnose and resolve common problems with the tractor.

Specifications

Product Specifications

Technical details and measurements for the Allis-Chalmers tractor model.

Limited Warranty

Warranty Period

Details on the duration of warranty coverage for different components.

Allis-Chalmers AC23460AWS Specifications

General IconGeneral
ManufacturerAllis-Chalmers
ModelAC23460AWS
CategoryLawn Mower
Fuel TypeGasoline
TypeWalk-behind
Engine TypeGasoline
Drive SystemRear-wheel drive
