LISTOFWARNINGS(cont'd)

Thismanualcontainsthefollowingwarnings—

ITISYOURRESPONSIBILITYTOBEFAMILIARWITHALLOFTHEM.

•Assumingproperinstallationofdirectionsignalwire134,

mostAllisonshiftselectorsmaystillbeusedtocommand

transmissiondirectionchangesinthesecircumstances.Dueto

thefailureoftheSAEJ1939datalinkcommunication,however,

theshiftselectorcannotdisplaytheselectedrange.Whenthis

conditionexists,itisadvisabletoslowlyandcarefullyapply

thethrottleeachtimeachangeofdirectionhasbeenselected

inordertoverifythedirectionofoperationbeforeaccelerating

thevehicle.
