V07309.02.00
RIGHT-FRONT VIEW
LEFT-REAR VIEW
PTO PROVISION
(TOP RIGHT POSITION)
TORQUE
CONVERTER
MODULE
STANDARD
REAR
COVER
COOLER PORTS
PTO PROVISION
MOUNTING PAD
MOUNTING PADS
(BOTH SIDES)
FILL TUBE
TURBINE-SPEED
SENSOR
ENGINE-SPEED SENSOR
PTO PROVISION
MAIN-PRESSURE TAP
NAMEPLATE
SOLENOID
CONNECTOR
RETARDER
TEMPERATURE
CONNECTOR
Figure 6. 4000/4500 EVS With PTO
(Allison 4
th
Generation Controls)
14
