5
WI-LSC905/3003-02
PROGRAMMING INSTRUCTIONS
FOR OPTIONAL ALLMAND LSC100 TIMER
The Allmand LSC100 Light Sequence Commander can be equipped with an optional 7 Day, 8 Event, program-
mable timer.
OVERVIEW
The LSC Timer allows full ON/OFF control of the LSC equipped light tower. The lights can be turned ON and
OFF at specific times of the day and as many as 8 times a day. The timer can also be programmed for a
specific day of the week or any combination of days.
SETTING TIME
To set the clock to your local time and the day of the week:
1. Press the CLOCK button and hold throughout the following steps.
2. Set the Day of the Week by pressing the DAY key until the correct day appears.
3. Set the HOUR by pressing the HOUR key until the desired Hour appears.
4. Set MINUTE by pressing the MIN key until the desired minute appears.
5. When the time and day is set, release the CLOCK key.
PROGRAMMING
1. Pressing the TIMER key will enter the Program mode. Pressing the TIMER key will scroll through the
events. Stop on the event you want to set. There are 8 events and an ON and OFF time for each
event.
2. Press DAY key to select the day or group of days. Press the HOUR key to set the hour and the MIN
key to set the minute.
NOTE: You may never need to use more than 1 event ON and OFF per day. However the timer is capable of
8 event pairs per day. Always set an OFF time for each ON time.
NOTE: To clear the event, press the TIMER key until you get to the event you want to clear and hold, then
press the DAY key until the setting clears.
Always set an OFF time for each ON time. It is possible to have one OFF event for several ON events. For
example, if you want to have the lights come on at different times each day but go off at the same time every
day,one OFF event is all that is needed as long as it covers all of the ON days.
When the programming is complete, press the CLOCK key.
The MANUAL key on the timer will select ON, AUTO, and OFF. Position the black bar in the display window
over the desired function. For Automatic operation of the timer it must be set to AUTO.
With the LSC set with Power Switch ON and the AUTO/MANUAL switch to AUTO, the MANUAL TIMER key
can be used to initiate the start sequence by pressing the MANUAL key until it indicates ON. The shutdown
sequence can also be initiated by pressing the MANUAL key to indicate the OFF position.
All programming and time can be reset to new settings by pushing the RESET button with a pencil or pen.
NOTE: All programming will be lost when button is pushed
