17
TerraStreamer
®
ESE Terminal
Metallic Mast
Stainless Steel Cable Ties or
Mounting Brackets
Strike Counter
Inspection Well
Fig. K - Tower Top Location
5. Lightning Strike Counter Installation
The Lightning Strike Counter should be installed at a position along the
down conductor length where it can be accessed easily for inspection.
Typically the strike counter should be installed approximately 2m from
ground level.
The strike counter should be mounted away from areas where damage/loss
may occur due to theft, vandalism or damage from nearby operations.
The strike counter can be enclosed in a security enclosure but the display
should be kept visible to allow for the checking of recorded strikes.
