Diagram: Fuse terminal hardware
Any application where there is a battery pack, a fuse must be
installed. A fuse will open the battery circuit and prevent any
serious damage from occurring.
The fuse should be installed on or between the battery terminals.
The main B+, B- or in-between 2 batteries is an acceptable
location. The fuse must be rated for pack voltage and fault current.
