Allview 24ATC5000-H - Main Unit

4EN
MAIN UNIT
1. LED display screen
2. Remote control sensor / Power indicator- In standby mode the indicator light is red;
when switching on the unit the indicator light is blue color.
3. Stand holder
4. VOL +/- button- To increase/decrease the volume level or move left/right.
5. CH +/- button- To select next/previous channel or move up/down.
6. MENU button- To enter menu setting page.
7. SOURCE button- To select the input source.
8. POWER button- To turn the TV ON/OFF.
1. AC Power cord
7. COAXIAL Output
2. EARPHONE output
8. CI+ Slot
3. SCART Input
9. Mini AV Input
4. PC AUDIO Input
10. Mini YPbPr Input
5. VGA Input
11. USB Input
6. HDMI Input
12. RF Antenna input - Connect the ext. antenna
Back View
