PE6500/50
BATTERIES : General :
Before use, read the instructions given by the battery manufacturer
WARNING High Energy Hazard
Each external battery string MUST be protected according to the system power and the
installed cross-section of the cables
The fuse or disconnecting device must be capable of interrupting the current in the event
of a short-circuit.
The short-circuit current of the batteries is specified by the manufacturer
Shock hazard : all metal parts of batteries are alive and so there is a danger of injury from
electric shock and of accidental short circuit. Touch the battery on the insulated part only.
Be careful with non-insulated tools, bracelets and rings.
Explosion hazard : regardless of service conditions, hydrogen gas can escape from the
press
ure relief valves. Installation in hermetically enclosure is therefore prohibited.
M4
Reference
mating connector
Molex Minifit
2-pole Socket
+ & - are FLOATING
1
-
+
1
-
+
1
-
+
1
-
+
A
RJ 45
H
Out 1
Out 2
Out 3
Out 4
TO PE6500/60
Alarms
AC in
Grounding PE
1
-
+
Reference
mating connector
Mate-N-Lok
3 - pole Socket
Housing : 350766-1
Contacts (2x) : 926882-1
FRONT
F2
F3
F4
ON
OFF
F1
