Ref 4804 872 50293
PE6500/50
CONNECTION OF THE ADDITIONAL BATTERY BOX (PE6500/60)
1. Ensure that the battery breaker of the optional external battery box is open (down)
2. Place the battery cable between the two racks
3. Close the battery breaker of the external battery box
STARTING THE SYSTEM
1. Mains cable removed from the IEC rear socket or ensure that the mains is not connected to the system
2. Check that the battery breaker of the optional external battery box is open (down)
3. Check that the battery breaker of the main rack is open (down)
4. Connect the loads to the MAT-N-LOK connectors
5. Connect the mains to the rack
6. Eventually check the DC output voltage ; typical value : 54V
7. Close the battery breaker of the main rack
8. Close the battery breaker of the optional external battery
SWITCHING OFF THE SYSTEM
1. Open first the battery breaker of the optional external battery ( if present )
2. Open battery breaker of the main rack
3. Remove the mains from the main rack
Note: the TWO battery breakers (main rack AND optional rack) MUST be open to remove
the batteries from the system.
