Ref 4804 872 50293
PE6500/50
BLACK
RED
DO NOT
remove the insulation
for 2 battery strings
YELLOW
SHORT
BLACK
RED
- 48V - 2 x 7Ah
YELLOW
SHORT
YELLOW
LONG
YELLOW
LONG
YELLOW
SHORT
YELLOW
SHORT
- 48V - 1 x 7Ah
Do not place
the 3 yellow
cables in the
battery pack
Long wire 1
Long wire 2
Long wire 2
Long wire 1
