Alpha CD24 - Short Parts List

41
10 SHORT PARTS LIST
Reference
Burner - CD24
Burner - CD32
Main injector 5.0 mm - CD24
Main injector 6.6 mm - CD32
Primary heat exchanger - CD24
Primary heat exchanger - CD32
DHW heat exchanger - CD24C
DHW heat exchanger - CD32C
Gas valve - Honeywell VK4115V
Pump
Fan assembly - CD24
Fan assembly - CD32
Primary pressure switch
DHW flow regulator - CD24C
DHW flow regulator - CD32C
DHW flow switch - CD24C/CD32C
PCB
Flue thermostat
Ignition generator
Transformer
Temperature sensor
Fuse F2A
PCB fuse F315mA
Overheat thermostat
Expansion vessel 8 Litre
Pressure relief valve 3 bar
Automatic air vent
Pressure gauge
Ignition electrode and lead
Ignition electrode
Flame sensing electrode and lead - CD24
Flame sensing electrode and lead - CD32
Diverter valve assembly - CD24C/CD32C
By-pass assembly
Combustion chamber insulation panel front
Description British Gas GC No.
E94-407
E96-565
E94-409
E96-566
E94-408
E96-567
E57-739
E96-568
E94-410
E57-666
E94-411
E96-569
E76-320
E65-154
E96-570
E57-751
E94-412
E94-413
E94-414
E94-415
E76-317
E76-378
E96-571
E94-416
E57-702
E57-703
E57-709
E57-710
E94-417
E94-418
E94-419
E96-572
E57-773
E65-498
E94-420
Alpha Pt. No.
1.013172
1.018956
1.011848
1.019247
1.018030
1.018593
1.015957
1.018597
1.011846
1.015610
1.010659
1.016623
1.017496
1.011128
1.019465
3.013211
1.017788
1.012067
1.018162
1.012477
1.015970
1.6098
1.013931
1.018031
1.015394
1.011126
1.010771
1.016151
3.013626
1.016779
1.018163
1.019293
3.012752
3.012801
1.014732
Qty.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Fig. 27
Fig. 27
Fig. 2A/2B, item 6/31
Fig. 2B, item 31
Fig. 32
Fig. 32
Fig. 34
Fig. 34
Fig. 24
Fig. 33
Fig. 28
Fig. 28
Fig. 33
Fig. 2B, item 1
Fig. 2B, item 1
Fig. 31
Fig. 30
Fig. 28
Fig. 28
Fig. 28
Figs. 34 and 28
Fig. 20
Fig. 30
Fig. 28
Fig. 2A,2B, item 14
Fig. 33
Fig. 33
Fig. 33
Fig. 28
Fig. 28
Fig. 28
Fig. 28
Fig. 31 and 35
Fig. 2A,2B, item 26/27
Fig. 27
Alpha CD24/32 - Short Parts List
