1. Remove screw from the bottom of the heater and lift up the cover
2. Mark out 4 mounting points on the wall and drill them with 5.0mm diametre drill bit
Install wall plugs and install the heater onto the wall with the provided screws
3. Connect stop valve to heater inlet together with the rubber seal / washer
Connect Flexible hose to the heater Outlet and then turn on water supply to drain out plumbing dirt and fill up
the heater tank (this step will prevent damage to the heater tank)
4. Connect hand shower to the flexible hose, make sure the filter Mesh Washer is used.
1
4
2
3
13
