BRACKET ASSEMBLY HALTERMONTAGE SUPPORT DE MONTAGE10.
SOCKET ASSEMBLY SOCKELMONTAGE INSTALLATION DU SOCLE
INTEL LGA 4189
EN DE FR
Select the appropriate holder and plug it
together. Both holders are mounted identically.
Entsprechende Halterahmen wählen und
zusammenstecken. Beide Halterungen
werden identisch montiert.
Sélectionnez le cadre de maintien
correspondant et emboîtez-le. Les deux
supports sont montés de manière identique.
EN DE FR
Place the spacers on the threaded bolts.
Place the cooler with the holder on the base.
Screw the knurled nuts crosswise onto the
threaded bolts in the outer corners.
Platzieren Sie die Abstandshalter auf die
Gewindebolzen. Setzen Sie den Kühler mit
der Halterung auf den Sockel. Drehen Sie
die Rändelmuttern kreuzweise auf die
Gewindebolzen in den äußeren Ecken ein.
Placez les entretoises sur les boulons letés.
Placez le refroidisseur avec le support sur le
socle. Vissez les écrous moletés en croix sur
les boulons letés dans les coins extérieurs.
4x 6,5mm Spachers/
Abstandshalter/l‘entretoise
4x 4189 Knurled nuts/
Rändelmuttern/Ècrous moletès

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Alphacool Eisbaer Pro Series and is the answer not in the manual?

Alphacool Eisbaer Pro Series Specifications

General IconGeneral
Pump Speed2500 rpm
ExpandableYes
Hose Length400mm
Connector SizeG1/4"
Warranty2 years
Fan Size120 mm
CPU Socket CompatibilityIntel LGA 115x, 1200, 2011, 2011-3, 2066; AMD AM4, AM3(+), AM2(+), FM2(+), FM1
Radiator Size280 mm
Fan Speed500 - 2000 RPM
Pump Noise Level20 dB(A)
