C2/D2/
E2
B1/B2
F1/F2/F3
B1/B2
Spacers need to fill in the recessed holes on
the back of the TV, while keeping the
faceplate as close to the TV as possible.
Option E: For TVs with Recessed Holes
Use spacers to create extra space between
the TV and faceplate.
Option D: For TVs with Protruding Cables
C2/D2/
E2
F1/F2/F3
01A
01A
Alternate Spacer
Setups
Alternate Spacer
Setups
When you finish securing the TV bolts into the TV, please remember to
tighten nuts [H] using a socket wrench.
7/16″ (11mm)
Socket Wrench
(Not lncluded)
02 03 04
05 06 07 08
09
10 11 12 13 14
15 16
To Next Page
