Option B: For Curved TVs
Option A: For Flat Back TVs
C1/D1/E1
B1/B2
F1/F2
(If needed)
C2/D2/E2
B1/B2
F1/F2/F3
Option C: For TVs with a Bump
C2/D2/E2
B1/B2
F1/F2/F3
Alternate Spacer
Setups
Alternate Spacer
Setups
C1/D1/E1
B1/B2
F1/F2
(If needed)
Alternate Spacer
Setups
Alternate Spacer
Setups
Spacers must be tall enough so that the curved back of the TV does not interfere with the
mounting plate.
Add spacers if needed to fit the bolt length and TV back.
The faceplate must be flush on the bump and leveled by spacers on the gap.
