Supplied Parts and Hardware for Step 3
(Only one bolt size fits your TV.)
NOTE: The bolts are shown in actual size.
Level
x 1
07
Arm Assembly / Wall Plate
x 1
01B
Supplied Parts and Hardware for Step 2
[B1] x 4
Washer
M4 / M5
[B2] x 4
Washer
M6 / M8
M6
M8
M4
[C2] x 4
TV Bolt M4 x 30mm
[C1] x 4
TV Bolt M4 x 12mm
[D1] x 4
TV Bolt M6 x 15mm
[D2] x 4
TV Bolt M6 x 35mm
[E1] x 4
TV Bolt M8 x 25mm
[E2] x 4
TV Bolt M8 x 50mm
x 4
A1
Lag Screw
ST1/4 x 2 3/4″
NOTE: The lag screw is shown in actual size.
[F3] x 4
Spacer
L22mm
[F2] x 4
Spacer
L10mm
[F1] x 8
Spacer
L2.5mm
02 03 04
05 06 07 08 09
10 11 12 13 14
15 16
