Alphamount APTVS06 - Parts for TV Bracket Attachment (Step 3)

12 pages

To Next Page

To Previous Page

(05) x2

TV Bracket

Note: The bolts are shown in accordance with the actual size

Supplied Parts and Hardware for Step 3

[TV2] x4

M6 x 16mm

[TV3] x4

M6 x 35mm

[TV1]

[TV1-1] x4

M4 x 12mm

[TV1-2] x4

M4 x 30mm

[TV4] x4

M8 x 25mm

[TV5] x4

M8 x 50mm

Note: The washers and spacers are shown in accordance with the actual

size

[TV9] x4

10mm

[TV10] x4

22mm

[TV8] x8

2.5mm

Spacers

[if needed]

[TV6] x4

Washer

[TV7] x4

D8 Steel Washer

(J) x1

Safety Rope(Optional)
