F
01
Place foot pads [F] on the bottom of the tempered glass
base [01] in the corners.
Step 1-1
Supplied Parts for Step 4
(G) x2
Safety Lock
Step 1 Assemble the Base
04
Note：Kindly note that the tempered glass base is designed
to show the shiny glass side facing up
Supplied Parts and Hardware for Step 5 (Optional)
x1
A1
Lag Screw
ST6.3 x 45 mm
Note: The lag screw is shown in accordance with the actual size
Washer
D6
x1
A2
x1
A3
Wall
Anchor
M8x40mm
These anchors are for
concrete or brick walls
ONLY. DO NOT use them in
drywall or wood studs.
CAUTION!
To Next Page
