33-EN
01GB05CDA105E.fm
ALPINE CDA-105E 68-09359Z81-A (EN)
• The iPhone/iPod is not connected.
- Make sure the iPhone/iPod is correctly connected (refer to
“Connections” on page 37).
Make sure the cable is not bent excessively.
• There are no songs in the iPhone/iPod.
- Download songs to the iPhone/iPod and connect to this unit.
• Communication error.
- Turn the ignition key off, and then set to ON again.
- Reset the iPod.
- Check the display by reconnecting between the iPhone/iPod
and this unit, using the iPhone/iPod cable.
• Caused by the iPhone/iPod Software Version not being
compatible with this unit.
- Update the iPhone/iPod Software Version to be compatible
with this unit.
• The iPhone/iPod is not verified.
- Change another iPhone/iPod.
• Abnormal current is run to the USB connector device.
- You can solve the problem by switching the source, turning the
unit power off, or ACC to the OFF position.
• A USB device that is not supported by the unit is connected.
- Connect a USB device that is supported by the unit.
• Malfunction occurred as a result of the speaker cable shorting on
the car chassis.
- Route the cable correctly, and set POWER IC to ON (page 16).
If the above solution does not work, consult your nearest
dealer.
Specifications
FM TUNER SECTION
AM TUNER SECTION
CD PLAYER SECTION
USB SECTION
* Frequency response may differ depending on the encoder
software/bit rate.
PICKUP
GENERAL
CHASSIS SIZE
NOSEPIECE SIZE
• Due to continuous product improvement, specifications and design
are subject to change without notice.
Indication for iPod Mode
Indication for all Modes
Tuning Range 87.5-108.0 MHz
Mono Usable Sensitivity 9.3 dBf (0.8 µV/75 ohms)
50 dB Quieting Sensitivity 13.5 dBf (1.3 µV/75 ohms)
Alternate Channel Selectivity 80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
Capture Ratio 2.0 dB
Tuning Range 531-1,602 kHz
Sensitivity (IEC Standard) 22.5 µV/27 dB
Frequency Response 5-20,000 Hz (±1 dB)
Wow & Flutter (% WRMS) Below measurable limits
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
USB requirements USB 1.1/2.0
Max. Power Consumption 500 mA
USB Class Mass Storage
File System FAT 12/16/32
MP3 Decoding MPEG-1/2 AUDIO Layer-3
WMA Decoding Windows Media™ Audio
AAC Decoding AAC-LC format “.m4a” file
Number of Channels 2-Channel (Stereo)
Frequency Response* 5-20,000 Hz (±1 dB)
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
Wave length 795 nm
Laser power CLASS I
Power Requirement 14.4 V DC
(11-16 V allowable)
Maximum Power Output 50 W × 4
Maximum Pre-Output Voltage 2 V/10 k ohms
Bass ±14 dB at 100 Hz
Treble ±14 dB at 10 kHz
Weight 1.5 kg (3 lbs. 4 oz)
Width 178 mm (7)
Height 50 mm (2")
Depth 160 mm (6-1/4")
Width 170 mm (6-3/4")
Height 46 mm (1-13/16")
Depth 24 mm (15/16")
