Alpine CDA-9833R Service Manual

CDA-9833R
Ref. No. E C B
Q001 8.12/8.12 0/8.07 8.06/7.38
Q002 8.12/8.12 8.07/2.0 0/8.12
Q006 0 8.1 0
Q008 0 3.7 0
Q102 0/0 3.3/0 0/4.72
Q103 3.3/3.3 3.25/0 2.6/3.3
Q304 0 8.2 0.0
Q401 0/0 0/10.46 4.94/0
Q402 0/0 0/10.46 4.94/0
Q403 0/0 0/10.4 4.94/0
Q404 0/0 0/10.6 4.94/0
Q405 0/0 0/8.99 0.75/0
Q406 0/0 9.21/0 0/0.76
Q407 0/0 0/6.05 0.72/0
Q408 0/0 0/6.05 0.72/0
Q413 0.11 0.21 0
Q414 0 0.11 0.76
Q415 8.1 11.74 8.72
Q419 6.75/0 6.67/0 4.93/0.71
Q420 0/0 6.76/0 0/0.71
Q421 4.38 4.98 4.93
Q502 8.6 14.4 9.2
Q505 4.81 PS 4.81
Q506 4.88 PS 4.88
Q507 0 PS 0
Q601 0 4.7 0
Q602 4.95 0 4.95
Q603 0/0 14.1/0 0/4.9
Q606 0 9.33/0 0/4.75
Q803 14.4 14.4 13.7
Q804 0 0 4.9
Q807 12.3 14.4 12.9
Q808 12.3 14.4 12.9
Q810 12.12 14.4 17.71
Q812 9.94 14.4 10.6
Q841 4.83/4.83 0/4.84 4.83/3.2
Q844 0 0 4.76
Q894 0/0 4.89/0 0/9.7
Q904 4.9 4.78 0
Q905 0 0 4.77
Ref. No. 1234NOTE
Q1003 2.41/0.61 7.83/7.77 7.83/2 0.94/0 FM/AM
Ref. No. 12345
Q005 0 4.83 4.96 8.04 0
Q101 0/4.88 4.77/0 4.77/4.9 4.72/0 0/0
Q201 0/8.37 8.33/0.3 8.4/8.4 4.76/0 0/0
Q501 0 14.4 14.4 4.77 0
Q809 0 41.38 14.4 4.9 0
NOTE
AUDIO GREEN ON/OFF
FM/AM
FM/AM
CD/TUNER
TUNER/CD
RED OUT OFF/ON
RED OUT OFF/ON
Others/BUZZER
Others/OPEN
CD /TUNER
DIMMER OFF/ON
NOTE
CD/TUNER
IN-INT OFF/ON
SEA GREEN ON/OFF
MENU ON/OFF
MX ON/OFF
AUDIO GREEN ON/OFF
2 LIT AMB OFF/ON
2 LIT GREEN ON/OFF
SEA AMB ON/OFF
TO CONTENTS
TO SCHEMATIC
- 36 -
