Alpine CDA-9833R Service Manual

CDA-9833R
Ref. No. 12345
Q813 0/14.4 14.4/0.15 14.4/14.4 4.89/0 0/0
Q815 0 4.89 4.91 4.89 0
Q817 0 4.86 4.88 6.33 0
Q821 0 4.89 4.91 2.66 0
Q825 0 14.4 14.4 4.88 0
Q872 14.4 0 14.4 0 0
Q1004 0/7.48 0/0 0/0 0/0.91 0/2.57
Ref. No. 123456
Q311 PS/0 0/0 PS/0 0/6.12 0/0 0/6.12
Q312 PS/0 0/0 PS/0 0/6.12 0/0 0/6.12
Q313 PS/0 0/0 PS/0 0/6.12 0/0 0/6.12
Q604 PS 4.95 PS PS 4.95 PS
[Measuring Conditions]
1.Power Supply Voltage : DC14.4V
2.Measuring Meter : Digital Multi Meter
3.Measuring Point Reference : Between GND
4.Measuring Condition : FM : 98.1MHz
MW : 999KHz
LW : 216KHz
CD : at playing Disc
NOTE
Others/A-MUTE
NOTE
Others/A-MUTE
Others/A-MUTE
FM/AM
FAN ON/OFF
TO CONTENTS
TO SCHEMATIC
- 37 -

Alpine CDA-9833R Specifications

General

Brand	Alpine
Model	CDA-9833R
Category	Car Receiver
Language	English
