Alpine CDA-9833R Service Manual

CDA-9833R
No. Symbol I/O Terminal Description
96 X1(NC) - No connect terminal.
97 X2 I Clock connect terminal.
98 DSP RESET I EPF-BUS2 communication RESET signal terminal.
99 D0
100 D1
101 D2
102 D3
103 D4
104 D5
105 A16 O External program address terminal.
106 DVSS - GND connect terminal.
107 A17
108 A18
109 A19
110 A20
111 CVSS - GND connect terminal.
112 DVDD - Power supply terminal. (+3.3V)
113 D6
114 D7
115 D8
116 D9
117 D10
118 D11
119 D12
120 SW-D I DISC position detection SW-D input terminal.
121 D13
122 D14
123 D15
124 MDATA O SERVO-LSI control communication Command data signal terminal.
125 CVDD - Power supply terminal. (+1.6V)
126 CVSS - GND connect terminal.
127 HDS1(PULL-DOWN) - Pull-down connect terminal.
128 DVSS - GND connect terminal.
129 HDS2(PULL-DOWN) - Pull-down connect terminal.
130 DVDD - Power supply terminal. (+3.3V)
131 A0
132 A1
133 A2
134 A3
135 STAT I SERVO-LSI control communication Status signal input terminal.
136 A4
137 A5
138 A6
139 A7
140 A8
141 A9
142 CVDD - Power supply terminal. (+1.6V)
143 A21 O External program address terminal.
144 DVSS - GND connect terminal.
I/O External program data terminal.
I/O External program data terminal.
I/O External program data terminal.
External program address terminal.O
O External program address terminal.
O External program address terminal.
TO CONTENTS
TO SCHEMATIC
- 47 -
