Alpine CDA-9833R Service Manual

CDA-9833R
No. Symbol I/O Terminal Description
48 SSEL O BCLK output signal terminal.
49 SCK I PF-BUS2 communication SCK signal terminal.
50 CVSS - GND connect terminal. (+1.6V)
51 HINT(PULL-DOWN) - Pull-down connect terminal.
52 CVDD - Power supply terminal. (+1.6V)
53 MSEL O LRCLK output signal terminal. (LR polarity, SMCK fixation)
54 CS I EPF-BUS2 communication CS signal terminal.
55 HRDY(PULL-DOWN) - Pull-down connect terminal.
56 DVDD - Power supply terminal. (+3.3V)
57 DVSS - GND connect terminal. (+3.3V)
58 /SRQ O EPF-BUS2 communication SRQ signal terminal.
59 PSEL O SRDATA output terminal.
60 STS O EPF-BUS2 communication STS signal terminal.
61 NC - No connect terminal.
62 HBIL(PULL-DOWN) - Pull-down connect terminal.
63 STBY I STBY demand signal terminal.
64 CLOCK I Sub code frame clock signal terminal. (fCLDCK=7.35kHz)
65 BLKCK I Sub code block clock signal terminal. (fBLDCK=75Hz)
66 IPFLAG I Interpolation flag signal input terminal. (H : Interpolation)
67 /SCK I EPF-BUS2 communication Logic reversal signal terminal of SCK.
68 CVDD - Power supply terminal. (+1.6V)
69 SW-A I DISC position detection SW-A input terminal.
70 CVSS - GND connect terminal. (+1.6V)
71 NC - No connect terminal.
72 DVSS - GND connect terminal. (+3.3V)
73 SW-C I DISC position detection SW-C input terminal.
74 S/PDIF O Digital. data (SPDIF) output terminal.
75 DVDD - Power supply terminal. (+3.3V)
76 DVSS - GND connect terminal. (+3.3V)
77 PULL-UP - Pull-up connect terminal.
78 PULL-DOWN
79 PULL-DOWN
80 HPI16(PULL-DOWN)
81 SW-B DISC position detection SW-B input terminal.
82 NC - No connect terminal.
83 EMU0
84 EMU1/OFF
85 TDO(PULL-DOWN)
86 TDI(PULL-DOWN)
87 TRST(PULL-DOWN)
88 TCK(PULL-DOWN)
89 TMS(PULL-DOWN)
90 CVSS - GND connect terminal. (+1.6V)
91 CVDD - Power supply terminal. (+1.6V)
92 HPIENA(PULL-DOWN) - Pull-down connect terminal.
93 DVSS - GND connect terminal. (+3.3V)
94 NC - No connect terminal.
95 Load-Motor1 O LOAD motor control terminal.
- Pull-down connect terminal.
Pull-down connect terminal.-
I Emulator terminal.
- 46 -
