CDA-9833R
TMS320DA150PGE160 : IC101
No. Symbol I/O Terminal Description
1 CVSS - GND connect terminal.
2 A22 O External program address terminal.
3 CVSS - GND connect terminal.
4 DVDD - Power supply terminal. (+3.3V)
5 A10 O External program address terminal.
6 Load-Motor2 O LOAD motor control terminal.
7 A11
8 A12
9 A13
10 A14
11 A15
12 CVDD - Power supply terminal. (+1.6V)
13 HAS(PULL-DOWN) - Pull-down connect terminal.
14 DVSS - GND connect terminal. (+3.3V)
15 CVSS - GND connect terminal. (+1.6V)
16 CVDD - Power supply terminal. (+3.3V)
17 NC - No connect terminal.
18 HR/W(PULL-DOWN) - Pull-down connect terminal.
19 READY - DVDD connect terminal.
20 RON/CS O External program chip selection signal terminal.
21 NC
22 NC
23 SDRAM_ROM/WE O External program read / write signal terminal.
24 NSTRB O External program memory strobe signal terminal.
25 NC
26 NC
27 RESET O The RESET request signal terminal to SERVO-LSI.
28 NC
29 NC
30 PULL-UP - Pull-up connect terminal.
31 CS I EPF-BUS2 communication CS signal terminal.
32 PULL-UP - Pull-up connect terminal.
33 DVDD - Power supply terminal. (+3.3V)
34 CVSS - GND connect terminal. (+1.6V)
35 STBY I EPF-BUS2 communication STBY signal terminal.
36 MLD O SERVO-LSI control communication Command load signal terminal.
37 CVSS - GND connect terminal. (+1.6V)
38 MCLK O SERVO-LSI control communication Command clock signal terminal.
39 HCNTL0(PULL-DOWN) - Pull-down connect terminal.
40 DVSS - GND connect terminal.
41 BCLK I BCLK input signal terminal.
42 NC - No connect terminal.
43 LRLK I LRCLK input signal terminal.
44 NC - No connect terminal.
45 SRDATA I SRDATA input signal terminal.
46 HCNTL1(PULL-DOWN) - Pull-down connect terminal.
47 CMD I EPF-BUS2 communication CMD signal terminal.
- No connect terminal.
- No connect terminal.
External program address terminal.O
- No connect terminal.
- 45 -
