Alpine CDA9813 User Manual

ECB
Q400 0 10.32/0.04 0/4.87
Q401 0 10.33/0.04 0/4.87
Q402 0 10.4/0.1 0/4.89
Q405 0 0 4.47
Q407 0 6.34/0 0/0.73
Q408 0 0/7.45 6.99/0
Q409 0.01 0.09/3.5 0.75/0.01
Q410 0.07 0.12/2.43 0.78/0.01
Q411 0 0.61 0.73
Q413 0.14/0.07 0.15/3.96 0.78/0.01
Q414 0 0.15/3.98 0.78/0
Q415 7.65/8.26 11.7/11.89 8.59/8.62
Q416 0.08/0.05 0.11/4.2 0.79/0
Q417 0 0 4.49
ECB
Q401 0 0.61 0.73
Q402 0 0.17/3.91 0.81/0.05
Q403 0.07/0 0.29/1.47 0.92/0.05
Q405 0 7.66/0.07 0.05/0.71
Q406 0 0.5/12.1 0.76/0
Q407 6.42/0 0.1/0.05 0.05/0.7
Q408 0 0.1/12 0.74/0
Q410 0 10.29/0.1 0/4.81
Q412 0 0.07/10.15 4.9/0
Q413 0 10.37/0.05 0/4.91
Q414 0 10.35/0.08 0/4.91
Q415 0 10.4/0 0/4.87
Q417 0 0.06 4.51
Q827 12.4 13 14.38
[Measuring Conditions]
1.Power Supply Voltage : DC13V
2.Measuring Mete
r
: Digital Multi Mete
r
3.Measuring Point Reference : Between GND
3.Measuring Condition : FM : 98.1MHz
AM : 999kHz
CD : at playing Disc
CDA-9815R MODEL ONLY
CDA-9813R MODEL ONLY
MX IND OFF/ON
TCR IND OFF/ON
BLACK OUT OFF/ON
BLACK OUT OFF/ON
DIMMER OFF/ON
BLACK OUT OFF/ON
TCR/EQ OFF/ON
DIMMER OFF/ON
EQ IND OFF/ON
DIMMER OFF/ON
GREEN/AMB
GREEN/AMB
GREEN/AMB
GREEN/AMB
GREEN/AMB
GREEN/AMB
DIMMER OFF/ON
DIMMER OFF/ON
EQ IND OFF/ON
MX IND OFF/ON
TCR IND OFF/ON
TCR/EQ OFF/ON
