Alpine CDA9813 - CD Deck Mechanism IC Data

(
CD Deck Mechanism
)
CD-DA MP3 CD-DA MP3 CD-DA MP3
1 3.3 3.3 9 1.7 1.7 17 2.6 2.3
2 - - 10 1.6 1.6 18 1.7 1.7
3 - - 11 1.6 1.6 19 1.4 1.3
4 1.7 1.7 12 2.5 2.0 20 0.3 0.6
5 1.7 1.7 13 3.3 3.0 21 2.5 2.4
6 0.3 0.2 14 1.6 1.7 22 1.3 1.1
7 2.5 2.5 15 1.6 1.7 23 0.1 1.7
8 2.0 2.0 16 1.6 1.7 24 0.1 0.1
CD-DA MP3 CD-DA MP3 CD-DA MP3
1 1.6 1.7 23 1.6 1.7 45 0.1 0.1
2 1.7 1.7 24 1.7 1.7 46 1.7 1.7
3 0.1 0.1 - 2.3 25 3.3 3.2 47 1.7 1.7
4 1.7 1.7 26 1.7 1.7 48 3.3 3.2
5 0.1 0.1 - 3.3 27 1.7 1.7 49 0.1 0.1
6 3.2 3.2 28 2.6 2.3 50 1.6 1.7
7 0.1 0.1 29 1.7 1.6 51 3.3 3.2
8 0.1 - 3.2 0.1 - 3.2 30 2.5 2.0 52 1.7 1.6
9 0.0 0.0 31 1.6 1.6 53 1.7 1.7
10 3.3 3.2 32 1.7 1.6 54 0.1 0.1
11 0.1 0.1 33 1.7 1.6 55 3.3 0.1 - 3.2
12 0.0 0.0 34 1.7 1.6 56 0.8 0.1
13 3.3 0.1 - 3.2 35 1.7 1.6 57 0.1 - 3.3 0.1 - 3.2
14 3.3 3.2 36 0.2 - 1.2 0.4 - 1.2 58 0.1 - 3.3 0.1 - 3.2
15 3.3 3.2 37 1.7 - 2.6 1.7 - 2.5 59 0.1 - 3.3 0.1 - 3.2
16 1.7 1.7 38 2.0 2.1 60 0.1 - 3.3 0.1 - 3.2
17 1.6 1.6 39 3.3 3.2 61 0.1 - 3.3 0.1 - 3.2
18 1.6 1.7 40 1.6 1.2 - 1.7 62 0.1 - 3.3 0.1 - 3.2
19 1.7 1.7 41 1.8 1.7 - 2.1 63 3.3 3.2
20 1.7 1.7 42 0.1 0.1 64 3.3 3.2
21 1.1 1.1 43 3.3 3.2
22 0.1 0.1 44 0.1 0.1
CD-DA MP3 CD-DA MP3 CD-DA MP3
1 0.1 0.1 11 3.8 3.8 21 3.3 3.3
2 1.7 1.7 12 3.0 3.0 22 1.7 1.6
3 1.6 1.7 13 3.3 3.3 23 1.7 1.6
4 1.7 1.7 14 3.6 3.5 24 1.7 1.6
5 1.7 1.7 15 3.6 3.5 25 1.7 1.6
6 1.7 1.7 16 3.2 3.2 26 1.7 1.6
7 1.5 1.5 17 3.4 3.4 27 1.7 1.6
8 7.0 7.0 18 3.4 3.4 28 0.1 0.1
9 0.1 0.1 19 0.1 0.1
10 0.1 0.1 20 1.7 1.6
IC101
IC102
IC103
