Alpine CDE-133EBT User Manual

10-EN
About MP3/WMA
CAUTION
Except for private use, duplicating audio data (including MP3/
WMA data) or distributing, transferring, or copying it, whether
for free or for a fee, without permission of the copyright holder is
strictly prohibited by the Copyright Act and by international
treaty.
What is MP3?
MP3, whose ocial name is “MPEG Audio Layer 3,” is a compression
standard prescribed by the ISO, the International Standardization
Organization and MPEG which is a joint activity institution of the IEC.
MP3 les contain compressed audio data. MP3 encoding is capable of
compressing audio data at extremely high ratios, reducing the size of
music les to as much as one-tenth their original size. This is achieved
while still maintaining near CD quality. The MP3 format realises such
high compression ratios by eliminating the sounds that are either
inaudible to the human ear or masked by other sounds.
What is WMA?
WMA, or “Windows Media
™
Audio,” is compressed audio data.
WMA is similar to MP3 audio data.
Method for creating MP3/WMA les
Audio data is compressed using software with MP3/WMA codecs. For
details on creating MP3/WMA les, refer to the user’s manual for that
software.
MP3/WMA les that are playable on this device have the le extensions
“mp3” / “wma”. Files with no extension cannot be played back (WMA
ver. 7, 8 and 9 are supported).
Supported playback sampling rates and bit rates
MP3
WMA
This device may not play back correctly depending on sampling rates.
ID3 tags/WMA tags
This device supports ID3 tag v1 and v2, and WMA tag.
If tag data is in an MP3/WMA le, this device can display the title (track
title), artist name, and album name ID3 tag/WMA tag data.
This device can only display single-byte alphanumeric characters (up to
30 for ID3 tags and up to 15 for WMA tags) and the underscore. For
non-supported characters, “NO SUPPORT” is displayed.
If information contains characters other than ID3 tag information, the
audio le may not be played back.
The tag information may not be correctly displayed, depending on the
contents.
Producing MP3/WMA discs
MP3/WMA les are prepared, then written to a CD-R or CD-RW using
CD-R writing software. A disc can hold up to 509 les/folders (including
Root Folders), and the maximum number of folders is 255.
Playback may not be performed if a disc exceeds the limitations
described above.
Media supported
The media that this device can play back are CD-ROMs, CD-Rs, and
CD-RWs.
Corresponding File Systems
This device supports discs formatted with ISO9660 Level 1 or Level 2.
Under the ISO9660 standard, there are some restrictions to remember.
The maximum nested folder depth is 8 (including the root directory).
The number of characters for a folder/le name is limited.
Valid characters for folder/le names are letters A-Z (all caps), numbers
0-9, and ‘_’ (underscore).
This device also can play back discs in Joliet, Romeo, etc., and other
standards that conform to ISO9660. However, sometimes the le
names, folder names, etc., are not displayed correctly.
Formats supported
This device supports CD-ROM XA, Mixed Mode CD, Enhanced CD
(CD-Extra) and Multi-Session.
This device cannot correctly play back discs recorded with Track At
Once or packet writing.
Order of les
Files are played back in the order that the writing software writes them
to the disc. Therefore, the playback order may not be what is expected.
Verify the writing order in the software’s documentation. The playback
order of the folders and les is as follows.
* e folder No./ folder Name will not be displayed if no le is contained
in the folder.
Bit rate
This is the “sound” compression rate specied for encoding. The higher
the bit rate, the higher the sound quality, but also the larger the les.
Sampling rate
This value shows how many times per second the data is sampled
(recorded). For example, music CDs use a sampling rate of 44.1 kHz, so
the sound is sampled (recorded) 44,100 times per second. The higher
the sampling rate, the higher the sound quality, but also the larger the
volume of data.
Encoding
Converting music CDs, WAVE (AIFF) les, and other sound les into the
specied audio compression format.
Tag
Song information such as track titles, artist names, album names, etc.,
written into MP3/WMA les.
Root folder
The root folder (or root directory) is found at the top of the le system.
The root folder contains all folders and les. It is created automatically
for all burned discs.
Sampling rates: 48 kHz, 44.1 kHz, 32 kHz, 24 kHz, 22.05 kHz, 16 kHz,
12 kHz, 11.025 kHz, 8 kHz
Bit rates: 8 - 320 kbps
Sampling rates: 48 kHz, 44.1 kHz, 32 kHz
Bit rates: 32 - 192 kbps
Terminology
Root folder
Folder MP3/WMA File
