Alpine CDE-136BT Quick Reference Guide

18
iPod/iPhone (Optional) / iPod/iPhone (Opcional) / iPod/
iPhone (Opcional)
English Português Español
An iPod/iPhone can be connected to this unit by
using the Interface cable for iPod (included with
iPod/iPhone).
Um IPod/iPhone pode ser conectado a esta
unidade através do uso do cabo de Iterface para
iPod/iPhone ( incluso com o iPod/iPhone).
Es posible conectar un iPod/iPhone a esta
unidad mediante el cable de interfaz para iPod
(suministrado con el iPod/iPhone).
Recalling the iPod Mode
Select the iPod mode.
Retomando o modo iPod
Selecione o modo iPod.
Invocación del modo iPod
Seleccione el modo iPod.
Pause and Playback Pause e Reprodução Pausa y reproducción

Alpine CDE-136BT Specifications

General

Audio system	4.0
MP3 playback	Yes
DVD Audio playback	No
Playback disc formats	CD audio
Audio formats supported	AAC, CD-A, MP3, WMA
Video formats supported	Not supported
AM band range	531 - 1602 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 281 kHz
Supported radio bands	DAB+, FM, LW, MW
Preset stations quantity	48
Impedance	4 Ω
Output power	200 W
RDS features	AF, PTY, RT, TA, TP
Product color	Multicolor
Volume control	Digital
Frequency range	5 - 20000 Hz
Disc types supported	CD, CD-RW
Audio output channels	4.0 channels
Equalizer bands quantity	3
Signal-to-Noise Ratio (SNR)	105 dB
Display type	LCD
Display digits	14 digits
Display number of lines	1 lines
Display number of colors	Monochrome
USB version	2.0
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP, HFP, HSP
USB ports quantity	1
Digital audio optical out	0
Apple docking compatibility	iPad, iPod
Cables included	USB
Material	Metal, Plastic
File format system	FAT 16/32
Power requirements	11 - 16 VDC
Compatible products	iPhone / iPod / Nokia
Remote control type	IR
Key illumination color	Multi
Number of optical discs	1 discs
Operating temperature (T-T)	-10 - 60 °C

Weight and Dimensions

Depth	161 mm
Width	178 mm
Height	50 mm
Weight	1500 g
