Alpine CDE-9881 - Connections

26-EN
01GB05CDE9881.fm
ALPINE CDE-9881 68-08564Z04-A (EN)
Connections
Antenna
Blue POWER ANT
Blue/White
Orange ILLUMINATION
Black GND
Yellow BATTERY
Green
Green/Black
White/Black
Gray
Violet/Black
Violet
To iPod
To power antenna
To amplifier
To the instrument cluster illumination
lead
Ignition Key
Battery
Speakers
Rear Left
Front Right
Rear Right
Amplifier
White
SPEAKER
RIGHT FRONT
SPEAKER
RIGHT REAR
SPEAKER
LEFT REAR
SPEAKER
LEFT FRONT
Front Left
REMOTE TURN-ON
Subwoofers
AUDIO INTERRUPT INPink/Black
Red IGNITION
Gray/Black
To vehicle phone
Amplifier
Amplifier
Rear Left
Rear Right
Front Left
Front Right
Speakers
