Alpine CDE-W203E User Manual

01GB05CDEW203E.fm
ALPINE CDE-W203E 68-14470Z10-A (EN)
27-EN
Connections
* When Subwoofer is OFF: Output is for Front speakers. When Subwoofer is ON: Output is for Subwoofer.
For details on how to set the Subwoofer to ON/OFF, see “Subwoofer On and Off” on page 16.
Antenna
Blue
Blue/White
Orange
ILLUMINATION
Black GND
Yellow BATTERY
Green
Green/Black
White/Black
Grey
Violet/Black
Violet
To iPhone/iPod (sold separately)
To power antenna
To amplifier
To the instrument cluster illumination lead
Ignition Key
Battery
Speakers
Rear Left
Front Right
Rear Right
White
SPEAKER
RIGHT FRONT
SPEAKER
RIGHT REAR
SPEAKER
LEFT REAR
SPEAKER
LEFT FRONT
Front Left
REMOTE TURN-ON
Front or
Subwoofers*
AUDIO INTERRUPT IN
Pink/Black
Red IGNITION
Grey/Black
To vehicle phone
Amplifier
Speakers
POWER ANT
or
To Bluetooth INTERFACE (KCE-400BT)
(sold separately)
01GB00CDEW203E.book Page 27 Monday, November 10, 2008 11:11 AM

Alpine CDE-W203E Specifications

General

Brand	Alpine
Model	CDE-W203E
Category	Car Receiver
Language	English
