10 typical equalizer settings are preset at the factory for a variety of
musical source material.
Loudness introduces a special low-and high-frequency emphasis at low
listening levels. is compensates for the ear’s decreased sensitivity to
bass and treble sound.
You can modify the Equalizer settings to create a response curve more
appealing to your personal taste. e setting of Bass, Mid and Treble can
be adjusted in this mode.
Setting item: FACTORY EQ
Setting item: LOUDNESS
Setting the Bass Bandwidth (WIDTH (Q))
Setting the Mid Bandwidth (WIDTH (Q))
Setting the Bass Centre Frequency (CENTER FRQ)
Setting the Mid Centre Frequency (CENTER FRQ)
Setting the Bass Level
Setting the Mid Level
Setting item: 3BAND EQ
Further setting items: BASS / MID / TREBLE
e
e
e
e
e
e
e
e
e
e
Setting contents:
USER / FLAT (Initial setting) / POPS / ROCK / NEWS / JAZZ /
ELEC DANCE / HIP HOP / EASY LIS / COUNTRY / CLASSICAL
Setting contents:
LOUD OFF (Initial setting) / LOUD ON
Turn the Rotary encoder to select the desired bass
bandwidth.
WIDE 0.50
s
MEDIUM 1.00
s
MEDIUM 1.50
s
NARROW 2.00
Turn the Rotary encoder to select the desired Mid
bandwidth.
WIDE 0.75
s
MEDIUM 1.00
s
MEDIUM 1.25
s
NARROW 1.50
Turn the Rotary encoder to select the desired bass centre
frequency.
60 (Hz)
s
80 (Hz)
s
100 (Hz)
s
120 (Hz)
Emphasise the displayed bass frequency ranges.
Turn the Rotary encoder to select the desired Mid centre
frequency.
500 (Hz)
s
1.0k (Hz)
s
1.5k (Hz)
s
2.5k (Hz)
Turn the Rotary encoder to select the desired bass level
(-7~+7)
*
.
You can emphasise or weaken the bass level.
Turn the Rotary encoder to select the desired Mid level
(-7~+7)
*
.
You can emphasise or weaken the Mid level.
Changes the boosted bass bandwidth to wide or narrow. A wider setting
will boost a wide range of frequencies above and below the centre
frequency. A narrower setting will boost only frequencies near the centre
frequency.
Equalizer Presets (F-EQ)
Turning Loudness On/O
Adjusting the Parametric Equalizer Curve
(3BAND EQ)
Setting the Bass Control
Setting the Mid Control
Setting the Treble Control
1
1
1
2
2
2
3
3
3
After selecting BASS from the 3BAND EQ adjustment mode,
turn the Rotary encoder to select the desired Bass setting
item, and then press
s
/ENTER.
WIDTH (Q)
s
CENTER FRQ
s
LEVEL
After selecting MID from the 3BAND EQ adjustment mode,
turn the Rotary encoder to select the desired Mediant
setting item, and then press
s
/ENTER.
WIDTH (Q)
s
CENTER FRQ
s
LEVEL
After selecting TREBLE from the 3BAND EQ adjustment
mode, turn the Rotary encoder to select the desired Treble
setting item, and then press
s
/ENTER.
WIDTH (Q)
s
CENTER FRQ
s
LEVEL
Turn the Rotary encoder to select the desired setting value,
and then press
s
/ENTER.
Turn the Rotary encoder to select the desired setting value,
and then press
s
/ENTER.
Turn the Rotary encoder to select the desired setting value,
and then press
s
/ENTER.
Press
c
to return to the previous step.
Press
c
to return to the previous step.
Press
c
to return to the previous step.
*
*
e adjustment can also be made by pressing AUDIO/SETUP
(CDE-W235EBT only) or press AUDIO(CDE-W233E only). Refer
to “Adjusting Subwoofer Level/Bass Level/Middle Level/Treble
Level/ Balance (Between Le and Right)/Fader (Between Front and
Rear)/Loudness/Defeat” on page 11.
e adjustment can also be made by pressing AUDIO/SETUP
(CDE-W235EBT only) or press AUDIO(CDE-W233E only). Refer
to “Adjusting Subwoofer Level/Bass Level/Middle Level/Treble
Level/ Balance (Between Le and Right)/Fader (Between Front and
Rear)/Loudness/Defeat” on page 11.
Setting the Treble Bandwidth (WIDTH (Q))
Setting the Treble Centre Frequency (CENTER FRQ)
e
e
Turn the Rotary encoder to select the desired treble
bandwidth.
WIDE 0.75
s
NARROW 1.25
Turn the Rotary encoder to select the desired treble centre
frequency.
7.5K (Hz)
s
10.0K (Hz)
s
12.5K (Hz)
s
15.0K (Hz)
Setting the Treble Level
e
Turn the Rotary encoder to select the desired treble level
(-7~+7)
*
.
You can emphasise or weaken the treble level.
12
-EN
•
If no operation is performed for 60 seconds, Sound menu mode is
cancelled.
