Alpine LC70-69P - Front Door Tear Down; Remove Door Handle Screws; Release Door Handle Mechanism; Detach Door Panel Clips

13 14
The nal screw is holding the door handle in place. Using a PH2 Phillips Head screw
driver remove the screw.
With the screws now in view, they an be removed with a PH2 Phillips screwdriver.
Tear Down: Front Door
6
5
The door panel is held on by plastic push clips around the perimiter of the door. Using
a trim removal tool pry up each one to release the door card.
Slide the handle mechanism towards the front of the vehcile and away from the door
to release it.
Tear Down: Front Door
8
7
