1 4.97 1 5.00 1 2.6m
2 4.68 2 8.03 2 2.6m
3 3.1m 3 2.9m 3 0.0m
4 N.C 4 N.C 4 3.3m
5 3.1m 5 2.9m 5 0.0m
6 2.7m
7 1.4m
8 1.1m
1 54.9m 5 -3.4m 9 0m 13 0.9m
2 4.56 6 0.5m 10 0m 14 0.9m
3 4.56 7 0.5m 11 0.45 15 0.9m
4 0.5m 8 0.45 12 0.45 16 0.5m
1 13.66 1 25.35 1 0.6m
2 2.9m 2 0.7m 2 -24.94
3 5.00 3 15.10 3 -15.35
GDS GDS
Q 301 21.45 -87.6m 25.34 Q 601 0.27 14.37 0.85m
Q 302 -21.09 -87.6m -24.93 Q 602 0.27 14.37 0.8m
Q 401 21.44 -80.8m 25.34 Q 603 0.27 14.37 0.9m
Q 402 -21.09 -82m -24.9 Q 604 0.27 14.37 0.84m
BCE BCE
Q 551 0.75m 4.99 0.78m Q 592 0.7 0.75m 1.1m
Q 561 4.87 0.21 5.05 Q 663 0.73 113.9m 3.1m
Q 581 16.3 5.17m 0.72m Q 664 13.67 14.36 14.37
Q 582 -8.98 -24.8 -24.9 Q 671 13.66 14.33 14.37
Q 584 1.0m 4.99 0.7m Q 672 0.67 54.8m 2.4m
12345
Q 593 NC 3.60 15.10 15.07 23.5m
[Measuring Conditions]
1.Power Supply Voltage : DC14.4V
2.Measuring Meter : Digital Multi Meter
3.Measuring Point Reference : Between GND
4.Measuring Condition : No signal input
IC551
IC602 IC605 IC606
IC522IC521
IC601
