MRP-T220
Electrical Parts List
*******MAIN P.W.Board
=======IC's
IC101 51E22130S01 IC, NJM 4560M-TE3
IC102 51E22130S01 IC, NJM 4560M-TE3
IC103 51E22130S01 IC, NJM 4560M-TE3
IC104 51E22130S01 IC, NJM 4560M-TE3
IC201 51E22130S01 IC, NJM 4560M-TE3
IC202 51E22130S01 IC, NJM 4560M-TE3
IC203 51E22130S01 IC, NJM 4560M-TE3
IC204 51E22130S01 IC, NJM 4560M-TE3
IC601 51E27890S01 IC,uPC 494GS
=======Transistors/FET's
Q501 48E22900S01 TR,2SA1037K-Q,R,S-CP
Q502 48E22900S01 TR,2SA1037K-Q,R,S-CP
Q503 48E22900S01 TR,2SA1037K-Q,R,S-CP
Q504 48E22900S01 TR,2SA1037K-Q,R,S-CP
Q505 48E22902S01 TR,2SC2412K-Q,R,S-T146-CP
Q506 48E22902S01 TR,2SC2412K-Q,R,S-T146-CP
Q507 48E22902S01 TR,2SC2412K-Q,R,S-T146-CP
Q508 48E22902S01 TR,2SC2412K-Q,R,S-T146-CP
Q509 48E22902S01 TR,2SC2412K-Q,R,S-T146-CP
Q510 48E22902S01 TR,2SC2412K-Q,R,S-T146-CP
Q511 48E09088S01 TR,KTC 3198-Y-RD
Q512 48E09088S01 TR,KTC 3198-Y-RD
Q513 48E09036S02 TR,KTA 1266-Y-RD
Q514 48E09036S02 TR,KTA 1266-Y-RD
Q515 48E08329S01 TR,KSC 2682-Y
Q516 48E08329S01 TR,KSC 2682-Y
Q517 48E23701S01 TR KTC 3228-0-RD
Q518 48E23701S01 TR KTC 3228-0-RD
Q519 48E23700S01 TR KTA 1275-0-RD
Q520 48E23700S01 TR KTA 1275-0-RD
Q521 48E22902S01 TR,2SC2412K-Q,R,S-T146-CP
Q522 48E22902S01 TR,2SC2412K-Q,R,S-T146-CP
Q523 48E27748S01 TR,KTD 718-O
Q524 48E27748S01 TR,KTD 718-O
Q525 48E27747S01 TR,KTB 688-O
Q526 48E27747S01 TR,KTB 688-O
Q601 48E29405S01 FET, IRFZ48N
Q602 48E29405S01 FET, IRFZ48N
Q603 48E23701S01 TR KTC 3228-0-RD
Q604 48E23700S01 TR KTA 1275-0-RD
Q701 48E22902S01 TR,2SC2412K-Q,R,S-T146-CP
Q702 48E22902S01 TR,2SC2412K-Q,R,S-T146-CP
Q703 48E22900S01 TR,2SA1037K-Q,R,S-CP
Q704 48E22900S01 TR,2SA1037K-Q,R,S-CP
Q705 48E22902S01 TR,2SC2412K-Q,R,S-T146-CP
Q706 48E22900S01 TR,2SA1037K-Q,R,S-CP
Q707 48E22902S01 TR,2SC2412K-Q,R,S-T146-CP
Q801 48E22900S01 TR,2SA1037K-Q,R,S-CP
Q802 48E23697S01 TR,DTA 144EK-T146-CP
Q803 48E22555S01 TR,DTC 144EK-T146-CP
Q804 48E22902S01 TR,2SC2412K-Q,R,S-T146-CP
Q805 48E31104S01 TR,KTC2874-B-RD
Q806 48E31104S01 TR,KTC2874-B-RD
Q901 48E23700S01 TR KTA 1275-0-RD
Q902 48E22903S01 TR,DTC 143EK-T-146-CP
=======Diodes
D501 48E22916S01 DIO,1SS133-T-77-AX
D502 48E22916S01 DIO,1SS133-T-77-AX
D503 48E22916S01 DIO,1SS133-T-77-AX
D504 48E22916S01 DIO,1SS133-T-77-AX
D602 48T65059W01DIO,REC F10P20F
D603 48T65059W02DIO,REC F10P20FR
D701 48E22916S01 DIO,1SS133-T-77-AX
D702 48E22916S01 DIO,1SS133-T-77-AX
D801 48E23703S01 DIO,1N 4003-AX
D802 48E22916S01 DIO,1SS133-T-77-AX
D803 48E22916S01 DIO,1SS133-T-77-AX
D804 48E22916S01 DIO,1SS133-T-77-AX
D805 48E23703S01 DIO,1N 4003-AX
D901 48E23703S01 DIO,1N 4003-AX
ZD601 48E22436S01 DIO,ZEN,MTZ-J-16-B-AX
ZD602 48E22436S01 DIO,ZEN,MTZ-J-16-B-AX
ZD701 48E08332S01 DIO,ZEN,MTZ-J-22-B-AX
ZD801 48E22917S01 DIO,ZEN,MTZ-J-6.8-A-AX
=======Coil
T901 24E26126S01 CHOKE TRANS 28m/m
=======Thermistor
TH701 48E20887S01 TH,YTD5-320(20K)-YEL
=======Transfomer
T601 25E29257S01
ASS'Y POWER TRANS
(7T/13T)
=======Switch
SW201 40E20895S01 S/W SSAF 123NA
(FILTER(80Hz))
=======Capacitors
C103 08E28764S01 CAP,CER 101-J-SL1H-CP
C104 08E28764S01 CAP,CER 101-J-SL1H-CP
C105 08E28764S01 CAP,CER 101-J-SL1H-CP
C106 08E28764S01 CAP,CER 101-J-SL1H-CP
C107 08E28760S01 CAP,CER 10R-D-SL1H-CP
C108 08E28760S01 CAP,CER 10R-D-SL1H-CP
C109 08E28760S01 CAP,CER 10R-D-SL1H-CP
C110 08E28760S01 CAP,CER 10R-D-SL1H-CP
C111 08E28762S01 CAP,CER 33R-J-SL1H-CP
C112 08E28762S01 CAP,CER 33R-J-SL1H-CP
C113 08E28760S01 CAP,CER 10R-D-SL1H-CP
C114 08E28760S01 CAP,CER 10R-D-SL1H-CP
C115 08E28769S01 CAP,CER 102-K-SL1H-CP
C121 08E28769S01 CAP,CER 102-K-SL1H-CP
C123 08E28769S01 CAP,CER 102-K-SL1H-CP
C124 08E28769S01 CAP,CER 102-K-SL1H-CP
C201 08E33406S01 CAP,MYL,333-J-RD(8.0*12)
C202 08E33406S01 CAP,MYL,333-J-RD(8.0*12)
C203 08E34952S01 CAP,MYL,822-J-RD
C204 08E34952S01 CAP,MYL,822-J-RD
C205 08E34953S01 CAP,MYL,183-J-RD
C206 08E34953S01 CAP,MYL,183-J-RD
C207 08E34953S01 CAP,MYL,183-J-RD
C208 08E34953S01 CAP,MYL,183-J-RD
C209 08E33353S01 CAP,MYL,223-J-RD(7.1*12)
