Alpine PKG-1000 - Page 23

Electronic Parts List Electronic Parts List
Driver Board Driver Board
Parts Number
Descri
p
tion
Location Parts Number
Descri
p
tion
Location
32-10622-221 1206 10uF 10V -20%/+80%
C713
35-22334-151 0603 22KΩ 5%
R517
056-000058-20 SMD 451616-N2-121A COILS
FB200
32-22034-1B1 0603 22
p
F 50V ±5%
C227
056-000058-20 SMD 451616-N2-121A COILS
FB604
32-22034-1B1 0603 22
p
F 50V ±5%
C331
056-000058-20 SMD 451616-N2-121A COILS
FB605
32-22034-1B1 0603 22
p
F 50V ±5%
C514
056-000058-20 SMD 451616-N2-121A COILS
FB606
32-22034-1B1 0603 22
p
F 50V ±5%
C515
141-14M20-100 14.318Mhz/20PF/30PPM/49US/SMD
Y500
32-22034-1B1 0603 22
p
F 50V ±5%
C516
141-14M20-100 14.318Mhz/20PF/30PPM/49US/SMD
Y700
32-22034-1B1 0603 22
p
F 50V ±5%
C517
35-12334-151 0603 12KΩ 5%
R510
32-22034-1B1 0603 22
p
F 50V ±5%
C518
35-15134-151 0603 150Ω 5%
R206
32-22034-1B1 0603 22
p
F 50V ±5%
C519
35-15134-151 0603 150Ω 5%
R228
32-22034-1B1 0603 22
p
F 50V ±5%
C520
35-15134-151 0603 150Ω 5%
R509
32-22034-1B1 0603 22
p
F 50V ±5%
C521
35-15434-151 0603 150KΩ 5%
R106
32-22034-1B1 0603 22
p
F 50V ±5%
C522
35-15434-151 0603 150KΩ 5%
R805
32-22034-1B1 0603 22
p
F 50V ±5%
C523
35-15434-151 0603 150KΩ 5%
R813
32-22034-1B1 0603 22
p
F 50V ±5%
C639
35-15334-151 0603 15KΩ 5%
R241
32-22034-1B1 0603 22
p
F 50V ±5%
C640
35-15334-151 0603 15KΩ 5%
R242
32-22034-1B1 0603 22
p
F 50V ±5%
C641
32-18022-2B1 0603 18
p
F 25V ±5%
C715
32-22034-1B1 0603 22
p
F 50V ±5%
C642
32-18022-2B1 0603 18
p
F 25V ±5%
C716
32-22034-1B1 0603 22
p
F 50V ±5%
C643
32-18022-2B1 0603 18
p
F 25V ±5%
C304
32-22034-1B1 0603 22
p
F 50V ±5%
C644
32-18022-2B1 0603 18
p
F 25V ±5%
C305
32-22034-1B1 0603 22
p
F 50V ±5%
C645
35-10234-151 0603 1KΩ 5%
R239
32-22034-1B1 0603 22
p
F 50V ±5%
C646
35-10234-151 0603 1KΩ 5%
R309
32-22034-1B1 0603 22
p
F 50V ±5%
C647
35-10234-151 0603 1KΩ 5%
R310
32-22034-1B1 0603 22
p
F 50V ±5%
C648
35-10234-151 0603 1KΩ 5%
R311
32-22034-1B1 0603 22
p
F 50V ±5%
C649
35-10234-151 0603 1KΩ 5%
R312
32-22034-1B1 0603 22
p
F 50V ±5%
C650
35-10234-151 0603 1KΩ 5%
R313
32-22034-1B1 0603 22
p
F 50V ±5%
C651
35-10234-151 0603 1KΩ 5%
R314
32-22034-1B1 0603 22
p
F 50V ±5%
C652
35-10234-151 0603 1KΩ 5%
R315
32-22034-1B1 0603 22
p
F 50V ±5%
C653
35-10234-151 0603 1KΩ 5%
R316
32-22034-1B1 0603 22
p
F 50V ±5%
C654
35-10234-151 0603 1KΩ 5%
R811
32-22034-1B1 0603 22
p
F 50V ±5%
C655
35-10234-151 0603 1KΩ 5%
R202
32-22034-1B1 0603 22
p
F 50V ±5%
C656
35-10234-151 0603 1KΩ 5%
R204
32-22034-1B1 0603 22
p
F 50V ±5%
C657
35-10234-151 0603 1KΩ 5%
R209
32-22034-1B1 0603 22
p
F 50V ±5%
C658
35-10234-151 0603 1KΩ 5%
R215
32-22034-1B1 0603 22
p
F 50V ±5%
C717
35-10234-151 0603 1KΩ 5%
R219
32-22034-1B1 0603 22
p
F 50V ±5%
C718
35-10234-151 0603 1KΩ 5%
R226
32-22034-1B1 0603 22
p
F 50V ±5%
C719
35-10234-151 0603 1KΩ 5%
R238
041-022320-00 1206 22uF/10V
C222
35-10234-151 0603 1KΩ 5%
R243
041-022320-00 1206 22uF/10V
C223
35-10232-111 1206 1KΩ 5%
R800
055-022U38-00 SMD 22uH 0.9A±10% 5D28 TYPE
L600
35-10534-151 0603 1MΩ 5%
R706
021-EEPROM-10 24LC04B-I 8PIN SOIC
U501
35-10534-151 0603 1MΩ 5%
R325
41-27000-010 27MHZ/49US/20PF/30PPM/SMD
Y300
42-N4148-030 SMD 1N4148
D101
43-39040-03B SMD 2N3904
Q
101
42-N4148-030 SMD 1N4148
D102
43-39040-03B SMD 2N3904
Q
600
42-N5819-021 SMD 1N5819
D501
43-39040-03B SMD 2N3904
Q
800
42-N5819-021 SMD 1N5819
D502
43-39040-03B SMD 2N3904
Q
801
42-SS355-014 1SS355TE-17 SOD-323 SMD
D500
43-39040-03B SMD 2N3904
Q
803
32-10511-2B1 0603 1uF 16V -20%/+80%
C126
43-39040-03B SMD 2N3904
Q
500
32-10511-2B1 0603 1uF 16V -20%/+80%
C806
43-39040-03B SMD 2N3904
Q
501
32-10511-2B1 0603 1uF 16V -20%/+80%
C807
43-39040-03B SMD 2N3904
Q
502
32-10511-2B1 0603 1uF 16V -20%/+80%
C808
43-39060-03B SMD 2N3906
(
PNP
)
SOT23
Q
100
32-10524-211 0805 1uF 50V -20%/+80%
C228
43-39060-03B SMD 2N3906
(
PNP
)
SOT23
Q
601
32-10524-211 0805 1uF 50V -20%/+80%
C229
43-39060-03B SMD 2N3906
(
PNP
)
SOT23
Q
804
32-10524-211 0805 1uF 50V -20%/+80%
C230
43-39060-03B SMD 2N3906
(
PNP
)
SOT23
Q
503
32-10524-211 0805 1uF 50V -20%/+80%
C231
43-K7002-010 SOT-23-CBE RK7002
Q
300
35-22234-151 0603 2.2KΩ 5%
R107
43-K7002-010 SOT-23-CBE RK7002
Q
301
046-2R2U23-00 C/C Y5V 2.2uF/16V ±5% 0805
C232
43-K7002-010 SOT-23-CBE RK7002
Q
802
046-2R2U23-00 C/C Y5V 2.2uF/16V ±5% 0805
C233
35-33234-151 0603 3.3KΩ 5%
R114
046-2R2U23-00 C/C Y5V 2.2uF/16V ±5% 0805
C234
35-33234-151 0603 3.3KΩ 5%
R224
046-2R2U23-00 C/C Y5V 2.2uF/16V ±5% 0805
C235
051-3R320-100 SMD 3.3uH±20% 4D18-3R3M
L200
35-22434-151 0603 220KΩ 5%
R102
032-300R24-50 1206 300Ω 5%
R104
35-22434-151 0603 220KΩ 5%
R200
35-30334-151 0603 30KΩ 5%
R815
35-20334-151 0603 20KΩ 5%
R111
35-30334-151 0603 30KΩ 5%
R214
35-22134-151 0603 220Ω 5%
R814
35-30114-151 0603 30Ω 5%
R324
32-22122-2B1 0603 220
p
F 50V ±5%
C300
35-30114-151 0603 30Ω 5%
R223
32-22122-2B1 0603 220
p
F 50V ±5%
C301
32-30034-1B1 0603 30
p
F 50V ±5%
C508
32-22122-2B1 0603 220
p
F 50V ±5%
C302
32-30034-1B1 0603 30
p
F 50V ±5%
C509
32-22122-2B1 0603 220
p
F 50V ±5%
C303
35-33134-151 0603 330Ω 5%
R232
032-220R24-50 1206 220Ω 5%
R801
35-33034-151 0603 33Ω 5%
R304
,
055-Y1006-100 SMD LY1006-221K 220uH 1KHz/1V
L100
35-33034-151 0603 33Ω 5%
R326
35-22334-151 0603 22KΩ 5%
R516
35-33034-151 0603 33Ω 5%
R327
