Alpine PKG-1000 - Page 24

Elect
r
o
n
ic
Pa
r
ts
List
Elect
r
o
n
ic
Pa
r
ts
List
Driver Board Driver Board
Parts Number
Descri
p
tion
Location Parts Number
Descri
p
tion
Location
35-33034-151 0603 33Ω 5%
R704
32-82122-2B1 0603 820
p
F 50V ±5%
C819
37-33037-087 0603 33Ω 8PIN 5%
RP300
032-082K02-30 0603 82K Ω 1%
R806
37-33037-087 0603 33Ω 8PIN 5%
RP301
35-51034-151 0603 51Ω 5%
R221
37-33037-087 0603 33Ω 8PIN 5%
RP700
35-91214-151 0603 9.1KΩ 5%
R236
37-33037-087 0603 33Ω 8PIN 5%
RP701
071-UD209-100 UDZ09 SOD-323 9.1V SMD
D100
37-33037-087 0603 33Ω 8PIN 5%
RP702
021-D8565-100 D8565 O
p
erational Am
p
lifiers
U202
37-33037-087 0603 33Ω 8PIN 5%
RP703
026-DP1610-10 1.2MHZ DC-DC STEP-UP CONVERT
E
U200
37-33037-087 0603 33Ω 8PIN 5%
RP704
023-E8800-100 SMD AME8800AEFT
(
SOT-89
,
3.3V
)
U502
37-33037-087 0603 33Ω 8PIN 5%
RP705
24-B3902-000 B3902 P8N CHANNEL 30-V
(
SO-8
)
U801
37-33037-087 0603 33Ω 8PIN 5%
RP706
022-DM4953-10 DUAL P-CHAMMEL FET SO-8
U101
37-33037-087 0603 33Ω 8PIN 5%
RP707
022-DM4953-10 DUAL P-CHAMMEL FET SO-8
U600
033-442R00-30 0603 442Ω 1%
R819
25-5964C-7AC SM5964C40J
U500
35-47234-151 0603 4.7KΩ 5%
R305
24-P9435-000 AP9435M APEC P-CHANNEL
(
SO-8
)
U604
35-47234-151 0603 4.7KΩ 5%
R306
28-T3102-0IV BIT3102A SMD S-O8
(
PWM IC
)
U100
35-47234-151 0603 4.7KΩ 5%
R307
28-IT113-100 BIT1132 SMD
Q
FP100 VGA TO XGA
U700
35-47234-151 0603 4.7KΩ 5%
R308
020-IT1675-10 Bit1675 Di
g
ital Video Decoder
U300
35-47234-151 0603 4.7KΩ 5%
R500
023-BI3193-10 Controller SSOP-16 Bitek
U800
35-47234-151 0603 4.7KΩ 5%
R501
121-12512-210 PH:1.25mm 12PIN SMD 90 de
g
ree
J500
35-47234-151 0603 4.7KΩ 5%
R600
120-35002-010 PH:3.5mm 2PIN SMD TYPE
CN800
35-47234-151 0603 4.7KΩ 5%
R601
121-050303-00 PH:0.5mm
(
FPT-30-A
)
30PIN
J400
35-47234-151 0603 4.7KΩ 5%
R816
121-050303-00 PH:0.5mm
(
FPT-30-A
)
30PIN
J401
031-47012-2A0 0603 4.7KΩ 8PIN 5%
RP500
121-125092-00 PH:1.25mm 9PIN SMD 90 de
g
ree
J600
031-47012-2A0 0603 4.7KΩ 8PIN 5%
RP501
071-A204U-100 DA204U UMD3
(
SOT-323
)
SMD
D801
046-2R2U33-00 1210 2.2uF/25V ±10%
C817
071-A204U-100 DA204U UMD3
(
SOT-323
)
SMD
D802
35-47134-151 0603 470Ω 5%
R817
102-DAN217-10 SMD DIODE DAN217 SOT-346
D201
32-47422-2C1 0805 470nF 25V -20%/+80%
C820
102-DAN217-10 SMD DIODE DAN217 SOT-346
D202
32-47022-2B1 0603 47
p
F 50V ±5%
C332
102-DAN217-10 SMD DIODE DAN217 SOT-346
D203
32-47022-2B1 0603 47
p
F 50V ±5%
C333
081-32169-100 3216FF-3A 1.6*3.2mm
F600
049-047U43-00 47U/25V 6.3*5.8 ±20%
C124
121-200132-01 PH：2.0mm 13PIN DIP 90
(
LOC
K
)
JP600
049-047U43-00 47U/25V 6.3*5.8 ±20%
C125
071-B160L-100 RB160L-40TE25 SMD
D600
049-047U43-00 47U/25V 6.3*5.8 ±20%
C634
023-111725-10 LD1117-2.5 1.0A SOT-223
U603
049-047U43-00 47U/25V 6.3*5.8 ±20%
C635
28-11173-13C 1117-3.3V SMD SOT-223
U601
049-047U43-00 47U/25V 6.3*5.8 ±20%
C636
28-11173-13C 1117-3.3V SMD SOT-223
U602
049-047U43-00 47U/25V 6.3*5.8 ±20%
C637
023-SL2980-10 VOLTAGE REGULATOR SOT-23 SI
I
U201
049-047U43-00 47U/25V 6.3*5.8 ±20%
C804
102-B0703C-10 Shottk
y
Barrier Diode
D200
049-047U43-00 47U/25V 6.3*5.8 ±20%
C805
42-B060L-014 SMD RB060L-40
D103
049-047U43-00 47U/25V 6.3*5.8 ±20%
C512
071-UDZS1-100 UDZS16B UMD2
(
SOD-323
)
SMD
D204
049-047U43-00 47U/25V 6.3*5.8 ±20%
C513
090-2000TS-10 UI9.8 13TS-2000TS
T800
049-047U43-00 47U/25V 6.3*5.8 ±20%
C809
24-K7002-000 RK7002T106 60V 115mA SOT-23
Q
102
049-047U43-00 47U/25V 6.3*5.8 ±20%
C810
056-03A221-00 SMD 220Ω±25% LCM-E0603A221
L511
16-10303-503 SMD 3*3 50KΩ
VR200
056-03A221-00 SMD 220Ω±25% LCM-E0603A221
L512
35-51134-151 0603 510Ω 5%
R234
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L503
35-51134-151 0603 510Ω 5%
R205
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L504
35-51334-151 0603 51KΩ 5%
R802
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L505
35-56234-151 0603 5.6KΩ 5%
R514
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L506
35-56234-151 0603 5.6KΩ 5%
R515
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L507
32-56322-2B1 0603 56nF 50V ±5%
C811
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L508
35-56434-151 SMD RES 560KΩ±5% 0603
R213
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L509
35-62234-151 SMD RES 6.2KΩ±5% 0603
R240
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L510
35-68134-151 0603 680Ω 5%
R512
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L601
35-68334-151 0603 68KΩ 5%
R812
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L602
32-68022-2B1 0603 68
p
F 50V ±5%
C127
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L603
32-68022-2B1 0603 68
p
F 50V ±5%
C400
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L604
32-68022-2B1 0603 68
p
F 50V ±5%
C402
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L605
32-68022-2B1 0603 68
p
F 50V ±5%
C403
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L606
046-068P15-00 1206
(
8P4R
)
ARRAY TYPE 68PE 50V
C404
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L607
046-068P15-00 1206
(
8P4R
)
ARRAY TYPE 68PE 50V
C405
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L608
046-068P15-00 1206
(
8P4R
)
ARRAY TYPE 68PE 50V
C406
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L609
046-068P15-00 1206
(
8P4R
)
ARRAY TYPE 68PE 50V
C407
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L610
046-068P15-00 1206
(
8P4R
)
ARRAY TYPE 68PE 50V
C408
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L611
046-068P15-00 1206
(
8P4R
)
ARRAY TYPE 68PE 50V
C409
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L612
102-UDZ75B-1
0
UDZ7.5B UMD2
(
SOD-323
)
SMD
D205
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L613
102-PTZ82B-10 RLZ8.2B
(
LL-34
)
8.2V SMD
D800
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L614
35-75034-151 0603 75Ω 5%
R300
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L615
35-75034-151 0603 75Ω 5%
,
R301
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L616
033-075K00-30 0603 75KΩ 1%
R809
056-03A601-00 SMD 600Ω±25% LCM-E0603A601
L617
033-075K00-30 0603 75KΩ 1%
R804
056-06A310-00 SMD 31Ω±25% LCM-E1206A310
L500
44-1PLCC-044 PLCC 44PIN SMD
U500
056-06A310-00 SMD 31Ω±25% LCM-E1206A310
L501
35-82234-151 0603 8.2KΩ 5%
R113
056-06A310-00 SMD 31Ω±25% LCM-E1206A310
L502
35-82434-151 0603 820KΩ 5%
R105
056-06A310-00 SMD 31Ω±25% LCM-E1206A310
L618
