Alpine PSS-22WRA - Amplifier Installation

Jeep
1
Use a 10mm socket to connect the power cable to
the POSITIVE (+) battery terminal. Note: The
NEGATIVE terminal should remain disconnected
until the installation is completed.
2
Amplifier Installation
Lift the engine cover and pull towards the front of
the vehicle to remove it.
3
Route the power cable through the blank grommet
on the firewall on the drivers side.
4
Route the power cable following the OEM harness
and secure it with the cable ties provided as shown
below.
5
Route the amplifier main harness up to the cluster
area following the OEM harness. (Shown in dashed
line)
6
Use the supplied cable ties to secure the main
harness to the dashboard frame with the inductors
between the vehicle’s body and dash board frame.
Jeep Wrangler
UNLIMITED JK • 10/19
Viewfromdriverside
betweenthebody
anddashboardframe
