Cautions on Power Supply Wires
Use the specified wire size according to the total fuse capacity of the amplifier to be installed and the wire
length.
For details on the wire size to be used, refer to the supplied “Cautions on Power Supply Wires Connection”
and the following connection example.
Connection example when installing an amplifier alone
• When the wire length from the amplifier to the vehicle’s battery is (A)
Wire size used for (A): 4 AWG/21 mm
2
(Max. length 8 m)
• External Fuse capacity: Make it equal to or larger than the fuse capacity of the amplifier
R2-A75M: equal to or larger than 80 A
R2-A60F: equal to or larger than 60 A
(A)
External Fuse
Vehicle’s chassis
Vehicle’s battery
Amplifier
Connection example when installing two amplifiers with a fuse capacity of 80 A
and one amplifier with 60 A
• When the wire length from each amplifier to the distribution block is 1 m
Wire size used for (B): 4 AWG/21 mm
2
• When the wire length from the distribution block to the vehicle’s battery is 5 m
Wire size used for (C): 1/0 AWG/53 mm
2
or 4 AWG/21 mm
2
x 2
• External Fuse capacity: Make it equal to or larger than total fuse capacity of the number of amplifiers
installed
80 A + 80 A + 60 A = equal to or larger than 220 A
Distribution block
(B)
(e.g. 80 A)
Amplifier
Vehicle’s chassis
External Fuse
Vehicle’s battery
Amplifier
Amplifier
(e.g. 80 A)
(e.g. 60 A)
(C)
NOTE:
• If the length of the power and ground cables exceed 1 m, or if you connect more than one amplifier, a
distribution block should be used.
SPECIFICATIONS
R2-A75M
Performance
Power Output
Per Channel, Ref.: 4 Ω, 14.4 V 500 W RMS × 1
Per Channel, Ref.: 2 Ω, 14.4 V 750 W RMS × 1
THD+N
Ref.: 10 W into 4 Ω ≤0.04%
Ref.: 10 W into 2 Ω ≤0.06%
Ref.: Rated Power into 4 Ω
≤
1.0%
Ref.: Rated Power into 2 Ω ≤1.0%
S/N Ratio
IHF A-wtd + AES-17
Ref.: 1 W into 4 Ω
>75 dB
IHF A-wtd + AES-17
Ref.: Rated Power into 4 Ω
>102 dB
Frequency Response
+0/–3 dB, Ref.: 1 W into 4 Ω 10 Hz - 400 Hz
+0/–1 dB, Ref.: 1 W into 4 Ω 15 Hz - 325 Hz
Damping Factor Ref.: 10 W into 4 Ω at 100 Hz >250
Control
Input Sensitivity
RCA Input
Ref.: Rated Power into 4 Ω
Hi: 0.4 - 10 V
Lo: 0.1 - 4.0 V
Crossover
Variable LPF
50 Hz - 400 Hz
(–24 dB/oct.)
Variable Subsonic
8 Hz - 40 Hz
(–24 dB/oct.)
Equalizer Bass EQ (fc=50 Hz)
0 to +12 dB
(Variable)
Remote Level* Linear Attenuation 0 to –20 dB
General
Input Impedance >10 kΩ
Preamp Output CH-1/2 Input Pass-through, Buffered 4 V max
Dimensions
Width 282 mm (11-1/8”)
Height 55 mm (2-3/16”)
Depth 165 mm (6-1/2”)
Weight 3.5 kg (7 lb 10 oz)
* Requires optional RUX-KNOB.2.
NOTE:
• Specifications and design are subject to change without notice.
