Altec TTP-343 Plus - User Manual

Questions and Answers

A
Andre CohenAug 15, 2025
What to do if Altec Barcode Reader is not printing?
- L
  Lori McfarlandAug 15, 2025
  If the Altec Barcode Reader is not printing, first ensure the interface cable is securely connected. If you're using a serial port, the cable pin configuration must be pin to pin; if it's not, replace the cable. Also, verify that the serial port settings are consistent between the host and the printer, and that the correct printer port is selected in the Windows driver. For Ethernet connections, ensure the IP address, subnet mask, and gateway are configured correctly.
T
Travis CarsonAug 18, 2025
Why does my Altec TTP-343 Plus show an error?
- W
  Wanda MccoyAug 18, 2025
  If your Altec Barcode Reader shows an error, it might be due to a lack of labels or ribbon, or incorrect printer settings. To resolve this: * If the label or ribbon has run out, load a new roll and press the FEED button. * If the printer settings are incorrect, initialize the printer using the "Power on Utility" or "Diagnostic Tool" instructions.
J
Julie JohnsonAug 22, 2025
How to troubleshoot Altec TTP-343 Plus Barcode Reader no response?
- S
  Suzanne PetersonAug 22, 2025
  If your Altec Barcode Reader is not responding, check the following: * Ensure the power switch is turned on. * Verify the green LED is lit on the power supply. If not, the power supply may be broken. * Confirm that both power connections, from the power cord to the power supply and from the power supply to the printer power jack, are securely connected.
S
sbrowningAug 26, 2025
What causes continuous feeding labels on Altec Barcode Reader?
- M
  Meagan BooneAug 26, 2025
  If the Altec Barcode Reader is feeding labels continuously, the printer settings may be incorrect. Initialize the printer and perform gap/black mark calibration to resolve this issue.
A
Adam MonroeAug 28, 2025
Why is there no print on the label from Altec TTP-343 Plus?
- C
  Cheyenne HansenAug 28, 2025
  If there is no print on the label from your Altec Barcode Reader, it could be due to incorrectly loaded labels or ribbon, or the ribbon may have run out. Follow the instructions for loading the media or loading the ribbon. If the ribbon is depleted, load a new ribbon.
M
Maria WadeSep 1, 2025
How to fix poor print quality on Altec TTP-343 Plus Barcode Reader?
- T
  tarabrownSep 1, 2025
  If you're experiencing poor print quality with your Altec Barcode Reader: * Ensure the top cover is completely closed and latched properly on both sides. * Reload the supply to make sure it is correctly installed. * Consider that the ribbon and media might be incompatible, and try changing the ribbon or label combination. * Check the print head for dust or adhesive accumulation and clean it if necessary.
T
Timothy WarnerSep 4, 2025
What to do if Altec Barcode Reader has paper jam?
- L
  Lisa HoltSep 4, 2025
  If you're experiencing paper jams with your Altec Barcode Reader: * Calibrate the gap/black mark sensor. * Ensure the label size is set correctly in the labeling software or program to match the installed paper. * Check for and remove any labels stuck inside the printer mechanism near the sensor area.
J
jamespadillaSep 7, 2025
What to do if Altec TTP-343 Plus Barcode Reader printer is paused?
- A
  Angela VillegasSep 8, 2025
  To resolve the issue of the Altec Barcode Reader being paused, simply press the FEED button to resume printing.
G
Gabrielle JohnstonSep 12, 2025
How do I check print head test pattern on Altec Barcode Reader?
- A
  Allen KingSep 12, 2025
  To check the print head test pattern on the Altec Barcode Reader for damage, run a printer self-test and check the pattern for any missing dots.

Summary

Printer Setup

3.1 Initial Printer Setup

3.2 Loading Ribbon and Labels

Diagnostic and Configuration Utilities

3.8 Diagnostic Tool Usage

How to launch and access the printer diagnostic software.

3.8.2 Printer Functions

Explains printer functions like sensor calibration and RTC setup.

3.9 Ethernet Configuration

Power-On Utilities

4.1 Sensor Calibration

Calibrating ribbon and media sensors for accurate printing.

4.2 Self-Test and Dump Mode

Performing printer self-test and entering dump mode.

4.3 Printer Initialization

Resets printer settings and clears memory to factory defaults.

Troubleshooting

6.1 LED Status Indicators

6.2 Print Quality Issues

Diagnosing and resolving issues affecting print output quality.

Altec TTP-343 Plus Specifications

General

Scanning Method	Laser
Type	Handheld
Interface	USB
Supported Barcodes	Code 39, Code 128
Reading Distance	Up to 30 cm
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 70°C
Humidity	5% to 95% (non-condensing)
Drop Specification	1.5 m onto concrete
