2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL
Page 26
5. PREPARATION: REMOVE SHOWN PLASTIC PANELS, COVERS, AND CAPS FIRST. See below.
a. Remove the caps and unscrew the OEM bolts, save for reuse.
b. Loosen the rubber strip and remove the driver side A pillar.
c. Detach top of the control panel without removing it.
(OPTIONAL) Remove control panel underneath the steering wheel for additional routing access.
d. Run harness through the OEM clip.
FUEL GAUGE ROUTING and INSTALL
c
a
a
b
a
a
b
c
d
