2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL
Page 9
1. Install grommet.
2. Remove the two or four Ford front bed bolts and discard.
3. With a hoist, lower the pre-assembled cylinder package in the bed of the truck. Be
careful not to damage the bed walls.
Secure with bolts provided.
• Two or four M12 - 1.75” x 110mm bolts and 1/2” washers into the front cylinder
plate. These two or four bolts replace the two front OEM bolts.
• Two or four 1/2”-13 x 2” bolts into the rear cylinder plate. Secure the rear plate
using the mounting backing plates underneath, combine with 1/2” washers and 1/2”
- 13 nylock nuts. Tighten each bolt to 70-75 ft-lbs of torque.
CYLINDER INSTALL - 6.5’ SHORT BED & 8’ LONG BED
6.5’ Bed 8’ Bed
