#8405 QUICKCHILLER INSTALLATION, OPERATION, AND MAINTENANCE
Pg. 26.
®
FOOD HANDLING GUIDELINES
P R O D U C T C A PA C I T Y P E R PA N :
Foods for chill or freeze processing should be portioned into shallow pans to a depth not to exceed
2-inches (51mm). The individual pan capacity chart below is provided as a general guideline to help
determine the number of processing loads required for the total quantity of food to be processed.
EXAMPLE: 132 lb per batch
÷ 12 lb per 12" x 20" x 2
1
/
2
" pan = 11 PANS
60 kg per batch
÷ 5,4 kg per 325mm x 530mm x 65mm pan = 11 PANS
Q U I C K C H I L L E R PA N C A PA C I T Y:
The following Quickchiller Capacity Chart indicates the number of pans that can be accommodated in the
appropriate size chiller for the chilling or freezing function. Additional pans can be accommodated only
when using the Quickchiller for holding at a refrigerated temperature or at a maintenance temperature for
frozen food.
DO NOT OVERLOAD THE QUICKCHILLER FOR THE PROCESSING FUNCTION.
Q U I C K C H I L L E R P A N C A P A C I T Y C H A R T
CHILLER NO. TOTAL METRIC
MODEL PANS STANDARD PAN SIZES WEIGHT GASTRONORM PAN SIZES TOTAL
QC-3 3 12" x 20" x 2
1
/
2
" pans 36 lb 530mm x 325mm x 65mm 1/1 16 kg
QC-20 5 12" x 20" x 2
1
/
2
" pans 60 lb 530mm x 325mm x 65mm 1/1 27 kg
10 18" x 26" x 1
1
/
2
" pans 60 lb n/a
QC-40 10 12" x 20" x 2
1
/
2
" pans 120 lb 530mm x 325mm x 65mm 1/1 54 kg
10 18" x 26" x 1
1
/
2
" pans 60 lb n/a
QC- 50 12 12" x 20" x 2
1
/
2
" pans 144 lb 530mm x 325mm x 65mm 1/1 65 kg
24 12" x 10" x 2
1
/
2
" pans 144 lb 265mm x 325mm x 65mm 1/2 65 kg
12 18" x 26" x 1
1
/
2
" sheet pans 72 lb n/a
QC-100 20 12" x 20" x 2
1
/
2
" pans 240 lb 530mm x 325mm x 65mm 1/1 109 kg
40 12" x 10" x 2
1
/
2
" pans 240 lb 265mm x 325mm x 65mm 1/2 109 kg
20 18" x 26" x 1
1
/
2
" sheet pans 120 lb n/a
*ADDITIONAL WIRE SHELVES REQUIRED FOR MAXIMUM CAPACITY
I N D I V I D U A L P A N C A PA C I T I E S
Steam Table Pan: 12" x 20" x 2
1
/
2
" 12 lb Gastronorm 1/1 530mm x 325mm x 65mm 5,4 kg
Steam Table Pan: 12" x 10" x 2
1
/
2
" 6 lb Gastronorm 1/2 265mm x 325mm x 65mm 2,7 kg
Full-Size Sheet Pan: 18" x 26" x 1
1
/
2
" 6 lb n/a
Half-Size Sheet Pans: 18 x 13 x 1
1
/
2
" 3 lb n/a
NOTE: All metric equivalent sizes and capacities shown throughout this manual are approximate.
*
*
*
*
*
*
