DESCRIPTION QUAN. PT. NO.
72" (1829mm) Food Probe Assembly 3 PR-3850
Cold Tube Sensors, 1-3/4" 3 14786
Sensor Mounting Block 1 BK-22636
ITEM DESCRIPTION QUAN. PT. NO.
CPU ENCLOSURE ASSEMBLY 1 15034
1. LCD Board Assembly 1 BA-33304
2. Door Lock 1 LK-23046
3. Door Gasket 4' (1219mm) GS-2019
5. Buzzer
6. Dip Switch
7. EPROM
8. PFI Adjust, P12
9. Write Protect Jumper
10. I/O Cable
11. J10 "—" Pin
12. CPU Board 1 BA-33100
13. Keys, Door Lock LK-24176
ITEM DESCRIPTION QUAN. PT. NO.
1. Filter-EMF 1 FI-3580
2. Compressor Fuse Blocks-15A (UPPER) 1 FU-3772
— Fuses, 15A, Glass G 2 FU-3775
2A. Compressor Fuse Block-20A (lower) 1 FU-33239
— Fuses, 20A, Class G 2 FU-33042
3. Terminal Block, 3 Pole 1 BK-33111
4. 24 Terminal Connector Block Assembly 1 15069
6. Transformer 1 TN-33480
7. Heat Sink (Self-contained Only) 2 HE-23421
8. Relay (Self-contained Only) 2 RL-33246
9. Relay Board 1 BA-33099
10. 30A Circuit Breaker (On/Off) 1 SW-3715
11. Relay Varister (Self-Contained Only) 2 RS-3578
12. Defrost Heater 3 Cosp RWE104
13. Defrost Heater Terminator Switch 3 Cosp RWE056
14. Door Heater 1 Cosp L2HR112
15. Door Switch Magnet 1 MA-3739
16. Door Switch 1 SW-33580
17. Fan Terminator Switch 3 CR-33388
#8400 Installation & Maintenance Manual - Pg. 12
3.1 — QC-50 CONTROL PARTS LIST, see page 13
3.2 — QC-50 ELECTRICAL PARTS LIST, see page 14
3.3 — QC-50 PROBES AND SENSORS
3.0 — Control & Component Parts Identification
