Alto-Shaam quickchiller QC-50 Installation And Maintenance Manual

1.1 INTRODUCTION
The Alto-Shaam® Quickchiller is a processing
refrigeration system designed to rapidly and uniformly
cool hot foods through the "chilling danger zone" of
140° to 40°F (60° to 4°C) in two hours or less. Fast
cooling minimizes microbial activity, thereby
controlling quality and sanitation in prepared foods.
As a result, a five-day storage life is achieved.
Chill processing stops all cooking activity. This enables
the operator to accelerate additional preparation
sequences. Chilling also enhances the freshly prepared
characteristics of foods.
Quick chill processing of prepared foods provides a
means to build refrigerated inventories of meals in
individual portions and bulk quantities. Chilled
inventories can be withdrawn and reheated as
required. For complete, comprehensive operating
instructions, refer to booklet No. 265, Quickchiller
Operating Procedure Guidelines.
1.2 SCOPE OF THE MANUAL
This technical manual provides sufficient
information for installation and general
maintenance of this equipment.
1.3 EQUIPMENT DESCRIPTION
The unit consists of the following parts:
a. Storage Compartment: The insulated food
storage compartment is clear storage area. This area
is dedicated to the rapid decrease of recently cooked
foods and as a short-term refrigerated storage area.
b. Door: Access to the storage compartment is
through a hinge-mounted insulated door. The door
includes a full gasket to provide a tight seal.
c. Evaporator Coil: The evaporator coil is located in
the storage compartment and functions as the
distribution point for the cold air associated with the
refrigeration system.
d. Cabinet: The cabinet is the enclosure consisting of
the above items.
e. Condensing Unit Compartment: This area contains
the condensing unit(s). Remote systems utilize a
condensing unit located elsewhere within or
external to the facility.
f. Electrical Enclosure: The electrical enclosure
includes the fuses, relays, and relay board.
1.4 EQUIPMENT SUPPLIED
The Quickchiller is shipped from the factory fully
assembled. The complete assembly is palletized
and crated to minimize the possibility of damage
in shipping and storage. The roll-in cart is
shipped separately. See Figure 1.1.
Table 1.4.1 - LEADING PARTICULARS
Distributor: Alto-Shaam, Inc.
Address: W164 N9221 Water Street
P.O. Box 450
Menomonee Falls, WI 53052-0450,
U.S.A.
Type: Quickchiller
®
Processing Refrigeration System
Model QC-50
(Self-Contained and Remote)
Purpose: To effectively speed the chilling
process of recently prepared,
hot foods.
Power Supply: QC-50 (Self-Contained and Remote)
208/230VAC
60 Hz, 1ph
30 AMP CIRCUIT RECOMMENDED
Refrigeration: 19160 BTU/HR (max.)
Drain Requirements: The chiller is furnished with a
drain tube (1/2" PVC) which exits
the bottom rear of the chiller. A
drain hose and floor drain are
required.
Water Requirements: None (unless unit is water-cooled)
Weights: QC-50 (Self-Contained)
Net Weight: 1200 lb. (544 kg)
Ship Weight: 1400 lb. (635 kg)
QC-50 (Remote)
Net Weight: 1000 lb. (453 kg)
Ship Weight: 1200 lb. (544 kg)
1.0 — General Information and Installation
#8400 Installation & Maintenance Manual - Pg. 1
